| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1T05_041T01_9000005234_36674cztM0_level2.evt | modeM0/AS1T05_041T01_9000005234_36674cztM0_level2_quad_clean.evt |
| Size (bytes) | 332,881,920 | 75,199,680 |
| Size | 317.5 MB | 71.7 MB |
| Events in quadrant A | 2,064,096 | 506,967 |
| Events in quadrant B | 2,260,032 | 508,098 |
| Events in quadrant C | 2,228,373 | 501,528 |
| Events in quadrant D | 3,248,417 | 470,680 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15 | 0 |
| B | 0 | 15 | 0 |
| C | 0 | 15 | 0 |
| D | 0 | 15 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 9009 | 2 |
| B | 0 | 9354 | 1 |
| C | 0 | 9044 | 1 |
| D | 0 | 12462 | 1 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 84 | 0 |
| B | 0 | 84 | 0 |
| C | 0 | 84 | 0 |
| D | 0 | 84 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 4115 | 14 | 0.340219% |
| B | 4115 | 87 | 2.114216% |
| C | 4115 | 66 | 1.603888% |
| D | 4115 | 186 | 4.520049% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 5548 | 4116 | 6 | 6 | 0.11% | 0.15% |  |
| B | 5548 | 4116 | 52 | 52 | 0.94% | 1.26% |  |
| C | 5548 | 4116 | 50 | 50 | 0.90% | 1.21% |  |
| D | 5548 | 4116 | 176 | 176 | 3.17% | 4.28% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 134731 | 1414.97 | 469 | 459 | 94.9 |
| A | 0 | 8 | 87622 | 918.53 | 469 | 459 | 94.9 |
| A | 9 | 143 | 15219 | 155.54 | 469 | 459 | 94.9 |
| B | 5 | 255 | 346380 | 3862.49 | 464 | 451 | 89.6 |
| B | 0 | 189 | 23013 | 251.92 | 464 | 451 | 89.6 |
| B | 0 | 221 | 22630 | 247.64 | 464 | 451 | 89.6 |
| C | 15 | 214 | 183272 | 1688.75 | 459 | 462 | 108.3 |
| C | 0 | 10 | 150225 | 1383.47 | 459 | 462 | 108.3 |
| C | 14 | 254 | 46556 | 425.8 | 459 | 462 | 108.3 |
| D | 2 | 249 | 424349 | 3775.38 | 454 | 441 | 112.3 |
| D | 7 | 223 | 386946 | 3442.26 | 454 | 441 | 112.3 |
| D | 12 | 227 | 202831 | 1802.51 | 454 | 441 | 112.3 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
