| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1C07_001T09_9000005236_36712cztM0_level2.evt | modeM0/AS1C07_001T09_9000005236_36712cztM0_level2_quad_clean.evt |
| Size (bytes) | 200,413,440 | 48,666,240 |
| Size | 191.1 MB | 46.4 MB |
| Events in quadrant A | 1,252,149 | 330,310 |
| Events in quadrant B | 1,323,802 | 334,857 |
| Events in quadrant C | 1,619,557 | 317,021 |
| Events in quadrant D | 1,696,495 | 306,095 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 52 | 0 |
| B | 0 | 52 | 0 |
| C | 0 | 52 | 0 |
| D | 0 | 52 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 3 | 0 |
| B | 0 | 3 | 0 |
| C | 0 | 3 | 0 |
| D | 0 | 4 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 5376 | 1 |
| B | 0 | 5611 | 1 |
| C | 0 | 6436 | 1 |
| D | 0 | 6880 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 2582 | 4 | 0.154919% |
| B | 2582 | 21 | 0.813323% |
| C | 2582 | 92 | 3.563129% |
| D | 2582 | 40 | 1.549187% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 2582 | 2582 | 0 | 0 | 0.00% | 0.00% |  |
| B | 2582 | 2582 | 15 | 15 | 0.58% | 0.58% |  |
| C | 2582 | 2582 | 75 | 75 | 2.90% | 2.90% |  |
| D | 2582 | 2582 | 35 | 35 | 1.36% | 1.36% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 107527 | 1809.49 | 291 | 286 | 59.3 |
| A | 9 | 143 | 8349 | 136.05 | 291 | 286 | 59.3 |
| A | 13 | 254 | 4652 | 73.67 | 291 | 286 | 59.3 |
| B | 5 | 255 | 117187 | 2128.32 | 285 | 279 | 54.9 |
| B | 15 | 85 | 15405 | 275.37 | 285 | 279 | 54.9 |
| B | 0 | 213 | 11229 | 199.35 | 285 | 279 | 54.9 |
| C | 0 | 10 | 234264 | 3703.08 | 269 | 271 | 63.2 |
| C | 14 | 254 | 216054 | 3414.89 | 269 | 271 | 63.2 |
| C | 15 | 214 | 116782 | 1843.85 | 269 | 271 | 63.2 |
| D | 13 | 36 | 314538 | 4578.47 | 276 | 268 | 68.6 |
| D | 13 | 249 | 123657 | 1797.6 | 276 | 268 | 68.6 |
| D | 2 | 153 | 45058 | 652.53 | 276 | 268 | 68.6 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
