| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A11_101T01_9000005238_36739cztM0_level2.evt | modeM0/AS1A11_101T01_9000005238_36739cztM0_level2_quad_clean.evt |
| Size (bytes) | 411,511,680 | 68,748,480 |
| Size | 392.4 MB | 65.6 MB |
| Events in quadrant A | 2,484,896 | 442,883 |
| Events in quadrant B | 2,670,428 | 459,593 |
| Events in quadrant C | 3,803,723 | 418,566 |
| Events in quadrant D | 3,168,834 | 415,205 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 10389 | 3 |
| B | 0 | 11037 | 2 |
| C | 0 | 14397 | 2 |
| D | 0 | 12735 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 98 | 0 |
| B | 0 | 98 | 0 |
| C | 0 | 98 | 0 |
| D | 0 | 98 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 36 | 0 |
| B | 0 | 36 | 0 |
| C | 0 | 36 | 0 |
| D | 0 | 37 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 4931 | 4 | 0.081119% |
| B | 4931 | 137 | 2.778341% |
| C | 4931 | 335 | 6.793754% |
| D | 4931 | 245 | 4.968566% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7054 | 4932 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7054 | 4932 | 9 | 9 | 0.13% | 0.18% |  |
| C | 7054 | 4932 | 283 | 283 | 4.01% | 5.74% |  |
| D | 7054 | 4932 | 200 | 200 | 2.84% | 4.06% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 209034 | 1788.01 | 585 | 575 | 116.6 |
| A | 13 | 254 | 8135 | 64.84 | 585 | 575 | 116.6 |
| A | 9 | 143 | 6115 | 47.52 | 585 | 575 | 116.6 |
| B | 5 | 200 | 216839 | 1978.57 | 580 | 567 | 109.3 |
| B | 0 | 213 | 55668 | 504.09 | 580 | 567 | 109.3 |
| B | 0 | 229 | 32986 | 296.59 | 580 | 567 | 109.3 |
| C | 14 | 254 | 742615 | 5857.95 | 549 | 555 | 126.7 |
| C | 0 | 10 | 705512 | 5565.05 | 549 | 555 | 126.7 |
| C | 15 | 214 | 203223 | 1599.9 | 549 | 555 | 126.7 |
| D | 12 | 227 | 630918 | 4682.47 | 553 | 539 | 134.6 |
| D | 13 | 249 | 143827 | 1064.35 | 553 | 539 | 134.6 |
| D | 13 | 171 | 108994 | 805.61 | 553 | 539 | 134.6 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
