| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A11_101T01_9000005238_36753cztM0_level2.evt | modeM0/AS1A11_101T01_9000005238_36753cztM0_level2_quad_clean.evt |
| Size (bytes) | 357,341,760 | 74,378,880 |
| Size | 340.8 MB | 70.9 MB |
| Events in quadrant A | 2,487,394 | 475,997 |
| Events in quadrant B | 2,759,802 | 499,289 |
| Events in quadrant C | 2,645,019 | 479,112 |
| Events in quadrant D | 2,594,364 | 452,195 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 10405 | 3 |
| B | 0 | 11275 | 2 |
| C | 0 | 10760 | 2 |
| D | 0 | 10849 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 100 | 0 |
| B | 0 | 100 | 0 |
| C | 0 | 100 | 0 |
| D | 0 | 100 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 39 | 0 |
| B | 0 | 39 | 0 |
| C | 0 | 39 | 0 |
| D | 0 | 40 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 4929 | 5 | 0.101440% |
| B | 4929 | 107 | 2.170826% |
| C | 4929 | 21 | 0.426050% |
| D | 4929 | 35 | 0.710083% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7021 | 4930 | 1 | 1 | 0.01% | 0.02% |  |
| B | 7021 | 4930 | 60 | 60 | 0.85% | 1.22% |  |
| C | 7021 | 4930 | 19 | 19 | 0.27% | 0.39% |  |
| D | 7021 | 4930 | 32 | 32 | 0.46% | 0.65% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 203681 | 1732.76 | 584 | 574 | 117.2 |
| A | 9 | 143 | 17747 | 146.51 | 584 | 574 | 117.2 |
| A | 13 | 254 | 6894 | 53.92 | 584 | 574 | 117.2 |
| B | 4 | 171 | 172493 | 1556.32 | 585 | 571 | 110.5 |
| B | 5 | 172 | 87352 | 785.58 | 585 | 571 | 110.5 |
| B | 0 | 213 | 75187 | 675.46 | 585 | 571 | 110.5 |
| C | 15 | 214 | 211718 | 1595.48 | 570 | 576 | 132.3 |
| C | 14 | 254 | 131553 | 989.72 | 570 | 576 | 132.3 |
| C | 0 | 10 | 44864 | 334.66 | 570 | 576 | 132.3 |
| D | 13 | 249 | 179410 | 1289.71 | 563 | 546 | 138.7 |
| D | 2 | 152 | 82982 | 594.41 | 563 | 546 | 138.7 |
| D | 13 | 171 | 63648 | 455.0 | 563 | 546 | 138.7 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
