| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A11_087T05_9000005240_36767cztM0_level2.evt | modeM0/AS1A11_087T05_9000005240_36767cztM0_level2_quad_clean.evt |
| Size (bytes) | 661,602,240 | 72,924,480 |
| Size | 631.0 MB | 69.5 MB |
| Events in quadrant A | 2,637,172 | 522,175 |
| Events in quadrant B | 11,428,185 | 287,685 |
| Events in quadrant C | 2,757,119 | 537,707 |
| Events in quadrant D | 2,869,165 | 502,332 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 10934 | 3 |
| B | 0 | 37400 | 2 |
| C | 0 | 11044 | 2 |
| D | 0 | 11780 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 40 | 0 |
| B | 0 | 40 | 0 |
| C | 0 | 40 | 0 |
| D | 0 | 40 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 106 | 0 |
| B | 0 | 106 | 0 |
| C | 0 | 106 | 0 |
| D | 0 | 106 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5094 | 8 | 0.157048% |
| B | 5094 | 3942 | 77.385159% |
| C | 5094 | 15 | 0.294464% |
| D | 5094 | 115 | 2.257558% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 9101 | 5096 | 2 | 2 | 0.02% | 0.04% |  |
| B | 9100 | 5093 | 3803 | 3803 | 41.79% | 74.67% |  |
| C | 9101 | 5096 | 14 | 14 | 0.15% | 0.27% |  |
| D | 9101 | 5096 | 81 | 81 | 0.89% | 1.59% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 201116 | 1597.79 | 617 | 605 | 125.5 |
| A | 9 | 143 | 28787 | 224.57 | 617 | 605 | 125.5 |
| A | 15 | 223 | 13949 | 106.33 | 617 | 605 | 125.5 |
| B | 12 | 1 | 10023657 | 164567.91 | 320 | 313 | 60.9 |
| B | 5 | 255 | 44854 | 731.29 | 320 | 313 | 60.9 |
| B | 0 | 213 | 26795 | 434.79 | 320 | 313 | 60.9 |
| C | 15 | 214 | 216010 | 1511.25 | 615 | 622 | 142.5 |
| C | 14 | 254 | 67769 | 471.13 | 615 | 622 | 142.5 |
| C | 0 | 10 | 39543 | 273.08 | 615 | 622 | 142.5 |
| D | 13 | 249 | 298738 | 2021.91 | 606 | 591 | 147.5 |
| D | 2 | 250 | 102090 | 688.33 | 606 | 591 | 147.5 |
| D | 1 | 47 | 45844 | 306.89 | 606 | 591 | 147.5 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
