| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A11_083T01_9000005242_36780cztM0_level2.evt | modeM0/AS1A11_083T01_9000005242_36780cztM0_level2_quad_clean.evt |
| Size (bytes) | 316,854,720 | 35,763,840 |
| Size | 302.2 MB | 34.1 MB |
| Events in quadrant A | 1,446,699 | 238,395 |
| Events in quadrant B | 2,523,168 | 233,493 |
| Events in quadrant C | 1,605,581 | 235,021 |
| Events in quadrant D | 3,832,356 | 178,201 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 56 | 0 |
| B | 0 | 56 | 0 |
| C | 0 | 56 | 0 |
| D | 0 | 56 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 19 | 0 |
| B | 0 | 19 | 0 |
| C | 0 | 19 | 0 |
| D | 0 | 19 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 5832 | 2 |
| B | 0 | 9297 | 1 |
| C | 0 | 6275 | 1 |
| D | 0 | 13258 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 2760 | 7 | 0.253623% |
| B | 2760 | 245 | 8.876812% |
| C | 2760 | 48 | 1.739130% |
| D | 2760 | 784 | 28.405797% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 4644 | 2761 | 0 | 0 | 0.00% | 0.00% |  |
| B | 4644 | 2761 | 163 | 163 | 3.51% | 5.90% |  |
| C | 4644 | 2761 | 40 | 40 | 0.86% | 1.45% |  |
| D | 4644 | 2761 | 706 | 706 | 15.20% | 25.57% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 108923 | 1536.32 | 342 | 334 | 70.7 |
| A | 13 | 6 | 7806 | 105.71 | 342 | 334 | 70.7 |
| A | 0 | 253 | 4512 | 59.11 | 342 | 334 | 70.7 |
| B | 12 | 1 | 1033530 | 15954.27 | 333 | 325 | 64.8 |
| B | 4 | 171 | 71815 | 1103.91 | 333 | 325 | 64.8 |
| B | 5 | 172 | 41273 | 632.29 | 333 | 325 | 64.8 |
| C | 14 | 254 | 185781 | 2360.13 | 329 | 331 | 78.6 |
| C | 15 | 214 | 117495 | 1491.09 | 329 | 331 | 78.6 |
| C | 0 | 10 | 10169 | 125.2 | 329 | 331 | 78.6 |
| D | 12 | 6 | 1563898 | 21680.76 | 291 | 283 | 72.1 |
| D | 12 | 227 | 372540 | 5161.64 | 291 | 283 | 72.1 |
| D | 12 | 233 | 322268 | 4464.58 | 291 | 283 | 72.1 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
