| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A11_075T01_9000005244_36872cztM0_level2.evt | modeM0/AS1A11_075T01_9000005244_36872cztM0_level2_quad_clean.evt |
| Size (bytes) | 331,617,600 | 55,267,200 |
| Size | 316.3 MB | 52.7 MB |
| Events in quadrant A | 2,661,232 | 428,060 |
| Events in quadrant B | 834,671 | 7,174 |
| Events in quadrant C | 2,757,797 | 441,982 |
| Events in quadrant D | 3,411,314 | 411,516 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 112 | 0 |
| B | 0 | 112 | 0 |
| C | 0 | 112 | 0 |
| D | 0 | 112 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11617 | 3 |
| B | 0 | 5561 | 2 |
| C | 0 | 11832 | 2 |
| D | 0 | 14138 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 30 | 0 |
| B | 0 | 30 | 0 |
| C | 0 | 30 | 0 |
| D | 0 | 31 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5462 | 19 | 0.347858% |
| B | 5462 | 5462 | 100.000000% |
| C | 5462 | 38 | 0.695716% |
| D | 5462 | 200 | 3.661662% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7285 | 5463 | 11 | 11 | 0.15% | 0.20% |  |
| B | 7284 | 5461 | 1 | 1 | 0.01% | 0.02% |  |
| C | 7285 | 5463 | 26 | 26 | 0.36% | 0.48% |  |
| D | 7285 | 5463 | 183 | 183 | 2.51% | 3.35% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 231983 | 1930.39 | 588 | 577 | 119.9 |
| A | 9 | 143 | 97372 | 807.47 | 588 | 577 | 119.9 |
| A | 7 | 3 | 25321 | 206.41 | 588 | 577 | 119.9 |
| B | 12 | 243 | 758035 | 186397.19 | 11 | 11 | 4.1 |
| B | 12 | 144 | 14036 | 3448.73 | 11 | 11 | 4.1 |
| B | 5 | 255 | 4554 | 1117.12 | 11 | 11 | 4.1 |
| C | 15 | 214 | 234205 | 1779.03 | 571 | 575 | 131.3 |
| C | 0 | 10 | 184508 | 1400.6 | 571 | 575 | 131.3 |
| C | 14 | 254 | 38592 | 289.49 | 571 | 575 | 131.3 |
| D | 13 | 249 | 500998 | 3665.4 | 562 | 548 | 136.5 |
| D | 12 | 17 | 280617 | 2051.28 | 562 | 548 | 136.5 |
| D | 13 | 171 | 153851 | 1122.82 | 562 | 548 | 136.5 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
