| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A11_075T01_9000005244_36875cztM0_level2.evt | modeM0/AS1A11_075T01_9000005244_36875cztM0_level2_quad_clean.evt |
| Size (bytes) | 355,196,160 | 59,785,920 |
| Size | 338.7 MB | 57.0 MB |
| Events in quadrant A | 2,874,149 | 463,582 |
| Events in quadrant B | 932,247 | 7,993 |
| Events in quadrant C | 2,934,300 | 476,809 |
| Events in quadrant D | 3,601,971 | 440,753 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 122 | 0 |
| B | 0 | 122 | 0 |
| C | 0 | 122 | 0 |
| D | 0 | 122 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12417 | 3 |
| B | 0 | 6156 | 2 |
| C | 0 | 12482 | 2 |
| D | 0 | 14911 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12 | 0 |
| B | 0 | 12 | 0 |
| C | 0 | 12 | 0 |
| D | 0 | 13 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5998 | 8 | 0.133378% |
| B | 5998 | 5998 | 100.000000% |
| C | 5998 | 32 | 0.533511% |
| D | 5998 | 216 | 3.601200% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7281 | 5999 | 5 | 5 | 0.07% | 0.08% |  |
| B | 7280 | 5997 | 0 | 0 | 0.00% | 0.00% |  |
| C | 7281 | 5999 | 25 | 25 | 0.34% | 0.42% |  |
| D | 7281 | 5999 | 186 | 186 | 2.55% | 3.10% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 245042 | 1807.03 | 658 | 643 | 135.2 |
| A | 9 | 143 | 34043 | 246.95 | 658 | 643 | 135.2 |
| A | 13 | 6 | 16385 | 116.39 | 658 | 643 | 135.2 |
| B | 12 | 243 | 830482 | 186900.02 | 13 | 13 | 4.4 |
| B | 12 | 144 | 15491 | 3483.38 | 13 | 13 | 4.4 |
| B | 5 | 172 | 13480 | 3030.8 | 13 | 13 | 4.4 |
| C | 15 | 214 | 256178 | 1715.47 | 640 | 644 | 149.0 |
| C | 0 | 10 | 88967 | 592.94 | 640 | 644 | 149.0 |
| C | 14 | 254 | 30352 | 199.44 | 640 | 644 | 149.0 |
| D | 13 | 249 | 700869 | 4580.82 | 630 | 613 | 152.9 |
| D | 13 | 171 | 111408 | 724.78 | 630 | 613 | 152.9 |
| D | 2 | 153 | 77507 | 503.01 | 630 | 613 | 152.9 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
