| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A11_075T01_9000005244_36878cztM0_level2.evt | modeM0/AS1A11_075T01_9000005244_36878cztM0_level2_quad_clean.evt |
| Size (bytes) | 1,790,357,760 | 259,479,360 |
| Size | 1.7 GB | 247.5 MB |
| Events in quadrant A | 14,014,631 | 1,951,927 |
| Events in quadrant B | 4,524,670 | 33,829 |
| Events in quadrant C | 14,700,289 | 1,981,438 |
| Events in quadrant D | 18,970,213 | 1,867,811 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 600 | 0 |
| B | 0 | 600 | 0 |
| C | 0 | 600 | 0 |
| D | 0 | 600 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 60497 | 7 |
| B | 0 | 29974 | 6 |
| C | 0 | 62069 | 6 |
| D | 0 | 77143 | 6 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 83 | 0 |
| B | 0 | 83 | 0 |
| C | 0 | 83 | 0 |
| D | 0 | 83 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 29305 | 66 | 0.225218% |
| B | 29305 | 29304 | 99.996588% |
| C | 29305 | 148 | 0.505033% |
| D | 29305 | 1239 | 4.227947% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 37753 | 29311 | 22 | 22 | 0.06% | 0.08% |  |
| B | 37752 | 29304 | 1 | 1 | 0.00% | 0.00% |  |
| C | 37753 | 29311 | 110 | 110 | 0.29% | 0.38% |  |
| D | 37753 | 29311 | 1040 | 1040 | 2.75% | 3.55% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 1038322 | 1581.26 | 3255 | 3189 | 654.6 |
| A | 9 | 143 | 144540 | 215.93 | 3255 | 3189 | 654.6 |
| A | 13 | 6 | 80609 | 118.27 | 3255 | 3189 | 654.6 |
| B | 12 | 243 | 4056664 | 265992.96 | 68 | 67 | 15.3 |
| B | 12 | 144 | 77180 | 5056.34 | 68 | 67 | 15.3 |
| B | 5 | 172 | 31104 | 2035.11 | 68 | 67 | 15.3 |
| C | 15 | 214 | 1238576 | 1699.79 | 3168 | 3187 | 726.8 |
| C | 0 | 10 | 243666 | 330.88 | 3168 | 3187 | 726.8 |
| C | 15 | 208 | 211671 | 286.86 | 3168 | 3187 | 726.8 |
| D | 13 | 249 | 1751316 | 2314.11 | 3124 | 3040 | 755.5 |
| D | 2 | 249 | 1217425 | 1607.43 | 3124 | 3040 | 755.5 |
| D | 12 | 233 | 1096274 | 1447.06 | 3124 | 3040 | 755.5 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
