| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A11_079T01_9000005254_36997cztM0_level2.evt | modeM0/AS1A11_079T01_9000005254_36997cztM0_level2_quad_clean.evt |
| Size (bytes) | 537,082,560 | 100,091,520 |
| Size | 512.2 MB | 95.5 MB |
| Events in quadrant A | 3,010,611 | 676,194 |
| Events in quadrant B | 5,458,253 | 646,649 |
| Events in quadrant C | 3,220,365 | 672,108 |
| Events in quadrant D | 4,182,641 | 629,789 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 120 | 0 |
| B | 0 | 120 | 0 |
| C | 0 | 120 | 0 |
| D | 0 | 120 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 36 | 0 |
| B | 0 | 36 | 0 |
| C | 0 | 36 | 0 |
| D | 0 | 36 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12648 | 3 |
| B | 0 | 20308 | 2 |
| C | 0 | 13060 | 2 |
| D | 0 | 16256 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5812 | 16 | 0.275292% |
| B | 5812 | 642 | 11.046111% |
| C | 5812 | 39 | 0.671025% |
| D | 5812 | 267 | 4.593944% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 9398 | 5814 | 3 | 3 | 0.03% | 0.05% |  |
| B | 9398 | 5814 | 482 | 482 | 5.13% | 8.29% |  |
| C | 9398 | 5814 | 29 | 29 | 0.31% | 0.50% |  |
| D | 9398 | 5814 | 219 | 219 | 2.33% | 3.77% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 229445 | 1608.11 | 715 | 701 | 142.2 |
| A | 9 | 143 | 10960 | 72.12 | 715 | 701 | 142.2 |
| A | 13 | 254 | 7619 | 48.63 | 715 | 701 | 142.2 |
| B | 5 | 184 | 2328201 | 18000.4 | 682 | 666 | 129.3 |
| B | 4 | 81 | 143010 | 1100.84 | 682 | 666 | 129.3 |
| B | 4 | 232 | 85202 | 653.77 | 682 | 666 | 129.3 |
| C | 15 | 214 | 250183 | 1547.61 | 696 | 704 | 161.2 |
| C | 0 | 10 | 74568 | 458.21 | 696 | 704 | 161.2 |
| C | 10 | 20 | 50125 | 306.58 | 696 | 704 | 161.2 |
| D | 1 | 52 | 738307 | 4360.78 | 687 | 669 | 169.2 |
| D | 2 | 250 | 472001 | 2786.43 | 687 | 669 | 169.2 |
| D | 2 | 153 | 122256 | 718.8 | 687 | 669 | 169.2 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
