| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A09_026T06_9000005278_37063cztM0_level2.evt | modeM0/AS1A09_026T06_9000005278_37063cztM0_level2_quad_clean.evt |
| Size (bytes) | 560,687,040 | 74,105,280 |
| Size | 534.7 MB | 70.7 MB |
| Events in quadrant A | 3,292,148 | 462,747 |
| Events in quadrant B | 4,336,902 | 448,597 |
| Events in quadrant C | 3,903,291 | 450,461 |
| Events in quadrant D | 5,010,852 | 431,501 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 26 | 0 |
| B | 0 | 26 | 0 |
| C | 0 | 26 | 0 |
| D | 0 | 26 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 134 | 0 |
| B | 0 | 134 | 0 |
| C | 0 | 134 | 0 |
| D | 0 | 134 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13742 | 3 |
| B | 0 | 17275 | 2 |
| C | 0 | 15514 | 2 |
| D | 0 | 19467 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6451 | 17 | 0.263525% |
| B | 6451 | 302 | 4.681445% |
| C | 6451 | 164 | 2.542242% |
| D | 6451 | 241 | 3.735855% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 9077 | 6453 | 6 | 6 | 0.07% | 0.09% |  |
| B | 9077 | 6453 | 216 | 216 | 2.38% | 3.35% |  |
| C | 9077 | 6453 | 155 | 155 | 1.71% | 2.40% |  |
| D | 9077 | 6453 | 202 | 202 | 2.23% | 3.13% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 295087 | 1935.05 | 745 | 727 | 152.1 |
| A | 9 | 143 | 39978 | 258.03 | 745 | 727 | 152.1 |
| A | 13 | 248 | 31029 | 199.2 | 745 | 727 | 152.1 |
| B | 5 | 184 | 782862 | 5613.84 | 729 | 708 | 139.3 |
| B | 5 | 172 | 228211 | 1632.88 | 729 | 708 | 139.3 |
| B | 0 | 221 | 126762 | 904.74 | 729 | 708 | 139.3 |
| C | 14 | 254 | 493212 | 2918.72 | 725 | 730 | 168.7 |
| C | 15 | 214 | 275203 | 1626.68 | 725 | 730 | 168.7 |
| C | 0 | 207 | 146544 | 864.17 | 725 | 730 | 168.7 |
| D | 1 | 52 | 653485 | 3679.32 | 724 | 704 | 177.4 |
| D | 12 | 235 | 409075 | 2301.74 | 724 | 704 | 177.4 |
| D | 12 | 17 | 216737 | 1217.64 | 724 | 704 | 177.4 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
