| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A11_079T01_9000005284_37174cztM0_level2.evt | modeM0/AS1A11_079T01_9000005284_37174cztM0_level2_quad_clean.evt |
| Size (bytes) | 418,608,000 | 99,074,880 |
| Size | 399.2 MB | 94.5 MB |
| Events in quadrant A | 2,893,531 | 676,498 |
| Events in quadrant B | 3,082,603 | 673,354 |
| Events in quadrant C | 3,085,689 | 659,358 |
| Events in quadrant D | 3,263,407 | 627,916 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 39 | 0 |
| B | 0 | 39 | 0 |
| C | 0 | 39 | 0 |
| D | 0 | 40 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 108 | 0 |
| B | 0 | 108 | 0 |
| C | 0 | 108 | 0 |
| D | 0 | 108 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11697 | 3 |
| B | 0 | 12345 | 2 |
| C | 0 | 12213 | 2 |
| D | 0 | 12962 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5181 | 16 | 0.308821% |
| B | 5181 | 71 | 1.370392% |
| C | 5181 | 61 | 1.177379% |
| D | 5181 | 112 | 2.161745% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7304 | 5182 | 7 | 7 | 0.10% | 0.14% |  |
| B | 7304 | 5182 | 29 | 29 | 0.40% | 0.56% |  |
| C | 7304 | 5182 | 53 | 53 | 0.73% | 1.02% |  |
| D | 7304 | 5182 | 94 | 94 | 1.29% | 1.81% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 258357 | 1948.33 | 665 | 654 | 132.3 |
| A | 13 | 248 | 38404 | 285.4 | 665 | 654 | 132.3 |
| A | 9 | 143 | 19062 | 139.17 | 665 | 654 | 132.3 |
| B | 5 | 172 | 214423 | 1731.76 | 646 | 631 | 123.5 |
| B | 0 | 155 | 67506 | 541.7 | 646 | 631 | 123.5 |
| B | 0 | 190 | 65519 | 525.61 | 646 | 631 | 123.5 |
| C | 15 | 214 | 222197 | 1515.09 | 633 | 640 | 146.2 |
| C | 0 | 10 | 209299 | 1426.89 | 633 | 640 | 146.2 |
| C | 10 | 49 | 94757 | 643.61 | 633 | 640 | 146.2 |
| D | 2 | 249 | 329589 | 2140.95 | 639 | 624 | 153.7 |
| D | 12 | 6 | 101404 | 655.89 | 639 | 624 | 153.7 |
| D | 10 | 253 | 94995 | 614.18 | 639 | 624 | 153.7 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
