| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A11_079T01_9000005284_37183cztM0_level2.evt | modeM0/AS1A11_079T01_9000005284_37183cztM0_level2_quad_clean.evt |
| Size (bytes) | 418,230,720 | 51,134,400 |
| Size | 398.9 MB | 48.8 MB |
| Events in quadrant A | 2,675,902 | 301,455 |
| Events in quadrant B | 2,790,172 | 300,439 |
| Events in quadrant C | 2,898,574 | 299,608 |
| Events in quadrant D | 3,938,562 | 272,279 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 29 | 0 |
| B | 0 | 29 | 0 |
| C | 0 | 29 | 0 |
| D | 0 | 30 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 108 | 0 |
| B | 0 | 108 | 0 |
| C | 0 | 108 | 0 |
| D | 0 | 108 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11194 | 3 |
| B | 0 | 11726 | 2 |
| C | 0 | 11684 | 2 |
| D | 0 | 15485 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5344 | 8 | 0.149701% |
| B | 5344 | 71 | 1.328593% |
| C | 5344 | 54 | 1.010479% |
| D | 5344 | 228 | 4.266467% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7046 | 5345 | 1 | 1 | 0.01% | 0.02% |  |
| B | 7046 | 5345 | 42 | 42 | 0.60% | 0.79% |  |
| C | 7046 | 5345 | 46 | 46 | 0.65% | 0.86% |  |
| D | 7046 | 5345 | 206 | 206 | 2.92% | 3.85% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 254793 | 2021.04 | 621 | 608 | 125.8 |
| A | 13 | 6 | 14642 | 111.58 | 621 | 608 | 125.8 |
| A | 13 | 254 | 8300 | 61.16 | 621 | 608 | 125.8 |
| B | 5 | 172 | 306693 | 2557.78 | 615 | 599 | 119.7 |
| B | 0 | 190 | 19547 | 158.33 | 615 | 599 | 119.7 |
| B | 12 | 111 | 15005 | 120.38 | 615 | 599 | 119.7 |
| C | 15 | 214 | 232643 | 1655.81 | 603 | 607 | 140.1 |
| C | 0 | 10 | 151036 | 1073.46 | 603 | 607 | 140.1 |
| C | 14 | 254 | 45640 | 321.36 | 603 | 607 | 140.1 |
| D | 10 | 253 | 749768 | 5166.08 | 592 | 575 | 145.0 |
| D | 2 | 249 | 440877 | 3036.11 | 592 | 575 | 145.0 |
| D | 1 | 52 | 335314 | 2308.2 | 592 | 575 | 145.0 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
