| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A11_027T01_9000005324_37463cztM0_level2.evt | modeM0/AS1A11_027T01_9000005324_37463cztM0_level2_quad_clean.evt |
| Size (bytes) | 502,490,880 | 105,465,600 |
| Size | 479.2 MB | 100.6 MB |
| Events in quadrant A | 4,308,924 | 708,984 |
| Events in quadrant B | 2,722,050 | 751,008 |
| Events in quadrant C | 2,951,952 | 737,979 |
| Events in quadrant D | 4,883,633 | 632,639 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 104 | 0 |
| B | 0 | 104 | 0 |
| C | 0 | 104 | 0 |
| D | 0 | 104 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 28 | 0 |
| B | 0 | 28 | 0 |
| C | 0 | 28 | 0 |
| D | 0 | 29 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 16316 | 3 |
| B | 0 | 11239 | 2 |
| C | 0 | 11581 | 2 |
| D | 0 | 17973 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5192 | 60 | 1.155624% |
| B | 5192 | 24 | 0.462250% |
| C | 5192 | 78 | 1.502311% |
| D | 5192 | 759 | 14.618644% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7315 | 5193 | 35 | 35 | 0.48% | 0.67% |  |
| B | 7315 | 5193 | 11 | 11 | 0.15% | 0.21% |  |
| C | 7315 | 5193 | 69 | 69 | 0.94% | 1.33% |  |
| D | 7315 | 5193 | 645 | 645 | 8.82% | 12.42% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 222 | 1522584 | 12644.27 | 614 | 604 | 120.4 |
| A | 10 | 83 | 269537 | 2234.24 | 614 | 604 | 120.4 |
| A | 13 | 248 | 107782 | 890.41 | 614 | 604 | 120.4 |
| B | 0 | 190 | 62526 | 534.91 | 623 | 608 | 115.8 |
| B | 0 | 213 | 59272 | 506.8 | 623 | 608 | 115.8 |
| B | 5 | 172 | 59089 | 505.22 | 623 | 608 | 115.8 |
| C | 15 | 214 | 220119 | 1553.86 | 616 | 622 | 141.3 |
| C | 0 | 10 | 193666 | 1366.6 | 616 | 622 | 141.3 |
| C | 14 | 254 | 70163 | 492.3 | 616 | 622 | 141.3 |
| D | 13 | 249 | 2153712 | 15846.03 | 563 | 548 | 135.9 |
| D | 12 | 235 | 228205 | 1675.42 | 563 | 548 | 135.9 |
| D | 1 | 47 | 97413 | 712.87 | 563 | 548 | 135.9 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
