| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1C07_001T11_9000005336_37559cztM0_level2.evt | modeM0/AS1C07_001T11_9000005336_37559cztM0_level2_quad_clean.evt |
| Size (bytes) | 480,882,240 | 101,684,160 |
| Size | 458.6 MB | 97.0 MB |
| Events in quadrant A | 2,848,959 | 689,128 |
| Events in quadrant B | 4,230,414 | 679,064 |
| Events in quadrant C | 2,878,887 | 676,065 |
| Events in quadrant D | 4,225,429 | 643,422 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11989 | 3 |
| B | 0 | 16713 | 2 |
| C | 0 | 12006 | 2 |
| D | 0 | 16282 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 17 | 0 |
| B | 0 | 17 | 0 |
| C | 0 | 17 | 0 |
| D | 0 | 18 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 116 | 0 |
| B | 0 | 116 | 0 |
| C | 0 | 116 | 0 |
| D | 0 | 116 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5594 | 11 | 0.196639% |
| B | 5594 | 142 | 2.538434% |
| C | 5594 | 38 | 0.679299% |
| D | 5594 | 233 | 4.165177% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7236 | 5595 | 2 | 2 | 0.03% | 0.04% |  |
| B | 7236 | 5595 | 102 | 102 | 1.41% | 1.82% |  |
| C | 7236 | 5595 | 30 | 30 | 0.41% | 0.54% |  |
| D | 7236 | 5595 | 224 | 224 | 3.10% | 4.00% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 344619 | 2673.47 | 629 | 617 | 128.7 |
| A | 12 | 189 | 31006 | 236.17 | 629 | 617 | 128.7 |
| A | 13 | 6 | 19267 | 144.94 | 629 | 617 | 128.7 |
| B | 4 | 80 | 1136459 | 9626.27 | 619 | 602 | 118.0 |
| B | 5 | 172 | 184722 | 1560.4 | 619 | 602 | 118.0 |
| B | 5 | 200 | 96091 | 809.26 | 619 | 602 | 118.0 |
| C | 15 | 214 | 259371 | 1819.95 | 610 | 611 | 142.2 |
| C | 14 | 254 | 125253 | 876.65 | 610 | 611 | 142.2 |
| C | 0 | 10 | 84700 | 591.43 | 610 | 611 | 142.2 |
| D | 2 | 249 | 855784 | 5800.48 | 607 | 590 | 147.4 |
| D | 12 | 235 | 370602 | 2509.66 | 607 | 590 | 147.4 |
| D | 5 | 222 | 168719 | 1140.36 | 607 | 590 | 147.4 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
