Observation information
- date-obs: 2022-09-30
- time-obs: 06:46:58.808800000
- date-end: 2022-09-30
- time-end: 08:51:55.804200000
- obs_id: C07_001T12_9000005352
- exposure: 4901.95952129
- sourceid: Blank Sky-8
- observer: tilak
- ra_pnt: 237.3919
- dec_pnt: 70.34809
Basic statistics of files
Param |
Original file |
Final file |
Filename | modeM0/AS1C07_001T12_9000005352_37882cztM0_level2.evt
| modeM0/AS1C07_001T12_9000005352_37882cztM0_level2_quad_clean.evt
|
Size (bytes) | 382,501,440 | 102,015,360 |
Size | 364.8 MB
| 97.3 MB
|
Events in quadrant A | 2,758,226 | 707,935 |
Events in quadrant B | 2,876,999 | 708,953 |
Events in quadrant C | 2,612,245 | 668,162 |
Events in quadrant D | 2,991,980 | 649,443 |
Level1 data integrity
Mode M9 |
Quadrant | BADHDUFLAG | Total packets | Discarded packets |
---|
A | 0 | 23 | 0 |
B | 0 | 23 | 0 |
C | 0 | 23 | 0 |
D | 0 | 24 | 0 |
Mode M0 |
Quadrant | BADHDUFLAG | Total packets | Discarded packets |
---|
A | 0 | 11112 | 3 |
B | 0 | 11510 | 2 |
C | 0 | 10681 | 2 |
D | 0 | 12081 | 2 |
Mode SS |
Quadrant | BADHDUFLAG | Total packets | Discarded packets |
---|
A | 0 | 104 | 0 |
B | 0 | 104 | 0 |
C | 0 | 104 | 0 |
D | 0 | 104 | 0 |
Data saturation
Quadrant | Total seconds | Saturated seconds | Saturation percentage |
---|
A | 5065 | 11 | 0.217177% |
B | 5065 | 116 | 2.290227% |
C | 5065 | 32 | 0.631787% |
D | 5065 | 60 | 1.184600% |
Noise dominated fraction
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
Quadrant |
# 1 sec bins |
Bins with >0 counts |
Bins with >2000 counts |
High rate bins dominated by noise |
Noise dominated (total time) |
Noise dominated (detector-on time) |
Marked lightcurve |
A | 7098 | 5066 | 7 | 7 | 0.10% | 0.14% |  |
B | 7098 | 5066 | 83 | 83 | 1.17% | 1.64% |  |
C | 7098 | 5065 | 23 | 23 | 0.32% | 0.45% |  |
D | 7098 | 5065 | 48 | 48 | 0.68% | 0.95% |  |
Top noisy pixels
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
Pixel properties |
Quadrant properties |
Quadrant |
DetID |
PixID |
Counts |
Sigma |
Mean |
Median |
Sigma |
A | 10 | 83 | 332978 | 2694.3 | 617 | 607 | 123.4 |
A | 12 | 227 | 22142 | 174.57 | 617 | 607 | 123.4 |
A | 12 | 189 | 8299 | 62.35 | 617 | 607 | 123.4 |
B | 5 | 172 | 412557 | 3657.59 | 602 | 589 | 112.6 |
B | 0 | 213 | 47922 | 420.24 | 602 | 589 | 112.6 |
B | 0 | 229 | 18743 | 161.18 | 602 | 589 | 112.6 |
C | 15 | 214 | 216488 | 1624.17 | 577 | 580 | 132.9 |
C | 0 | 10 | 111100 | 831.39 | 577 | 580 | 132.9 |
C | 14 | 254 | 27699 | 204.0 | 577 | 580 | 132.9 |
D | 1 | 52 | 182215 | 1276.86 | 589 | 572 | 142.3 |
D | 2 | 249 | 94391 | 659.5 | 589 | 572 | 142.3 |
D | 1 | 47 | 74966 | 522.95 | 589 | 572 | 142.3 |
Detector plane histogram (DPH)
Histogram calculated using DETX and DETY for each event in the final _common_clean file
Quadrant A |
 |
 |
Quadrant B |
Quadrant D |
 |
 |
Quadrant C |
Count rate plots and images
Plot type |
Count rate plots |
Images |
Comparison with Poisson distribution
Blue bars denote a histogram of data divided into 1 sec bins.
Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
Quadrant-wise count rates
Data is divided into 100 sec bins |
 |
 |
Module-wise count rates for Quadrant A
Data is divided into 100 sec bins |
 |
 |
Module-wise count rates for Quadrant B
Data is divided into 100 sec bins |
 |
 |
Module-wise count rates for Quadrant C
Data is divided into 100 sec bins |
 |
 |
Module-wise count rates for Quadrant D
Data is divided into 100 sec bins |
 |
 |
Housekeeping plots
Parameter |
Plot |
CZT HV Monitor |  |
D_VDD |  |
Temperature 1 |  |
Veto HV Monitor |  |
Veto LLD |  |
Alpha Counter |  |
_CPM_Rate |  |
CZT Counter |  |
+2.5 Volts monitor |  |
+5 Volts monitor |  |
_ROLL_ROT |  |
_Roll_DEC |  |
_Roll_RA |  |
Veto Counter |  |
