| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A07_145T01_9000005370_38273cztM0_level2.fits | modeM0/AS1A07_145T01_9000005370_38273cztM0_level2_quad_clean.evt |
| Size (bytes) | 358,174,080 | 93,591,360 |
| Size | 341.6 MB | 89.3 MB |
| Events in quadrant A | 2,674,289 | 632,545 |
| Events in quadrant B | 2,653,325 | 650,163 |
| Events in quadrant C | 2,652,382 | 627,157 |
| Events in quadrant D | 4,894,069 | 576,929 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 27 | 0 |
| B | 0 | 27 | 0 |
| C | 0 | 27 | 0 |
| D | 0 | 28 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 104 | 0 |
| B | 0 | 104 | 0 |
| C | 0 | 104 | 0 |
| D | 0 | 104 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 10872 | 3 |
| B | 0 | 10992 | 2 |
| C | 0 | 10660 | 2 |
| D | 0 | 18146 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 4946 | 9 | 0.181965% |
| B | 4946 | 84 | 1.698342% |
| C | 4946 | 36 | 0.727861% |
| D | 4946 | 70 | 1.415285% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7009 | 4947 | 5 | 5 | 0.07% | 0.10% |  |
| B | 7009 | 4947 | 54 | 54 | 0.77% | 1.09% |  |
| C | 7009 | 4947 | 32 | 32 | 0.46% | 0.65% |  |
| D | 7009 | 4947 | 54 | 54 | 0.77% | 1.09% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 373225 | 3171.15 | 585 | 573 | 117.5 |
| A | 12 | 189 | 23403 | 194.28 | 585 | 573 | 117.5 |
| A | 13 | 6 | 9280 | 74.09 | 585 | 573 | 117.5 |
| B | 5 | 184 | 141288 | 1261.73 | 588 | 572 | 111.5 |
| B | 5 | 172 | 82696 | 736.37 | 588 | 572 | 111.5 |
| B | 0 | 229 | 35727 | 315.22 | 588 | 572 | 111.5 |
| C | 15 | 214 | 208797 | 1522.2 | 586 | 593 | 136.8 |
| C | 0 | 10 | 86179 | 625.73 | 586 | 593 | 136.8 |
| C | 2 | 16 | 48030 | 346.82 | 586 | 593 | 136.8 |
| D | 10 | 203 | 2171845 | 15585.87 | 577 | 562 | 139.3 |
| D | 12 | 235 | 131542 | 940.2 | 577 | 562 | 139.3 |
| D | 2 | 250 | 94547 | 674.64 | 577 | 562 | 139.3 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
