| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A12_018T01_9000005386_38488cztM0_level2.fits | modeM0/AS1A12_018T01_9000005386_38488cztM0_level2_quad_clean.evt |
| Size (bytes) | 406,494,720 | 87,523,200 |
| Size | 387.7 MB | 83.5 MB |
| Events in quadrant A | 2,910,993 | 622,578 |
| Events in quadrant B | 3,102,136 | 628,025 |
| Events in quadrant C | 2,539,613 | 593,806 |
| Events in quadrant D | 6,088,842 | 440,813 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 106 | 0 |
| B | 0 | 106 | 0 |
| C | 0 | 106 | 0 |
| D | 0 | 106 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 18 | 0 |
| B | 0 | 18 | 0 |
| C | 0 | 18 | 0 |
| D | 0 | 18 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11727 | 2 |
| B | 0 | 12567 | 1 |
| C | 0 | 10772 | 1 |
| D | 0 | 21661 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5211 | 19 | 0.364613% |
| B | 5211 | 159 | 3.051238% |
| C | 5211 | 13 | 0.249472% |
| D | 5211 | 1166 | 22.375744% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7004 | 5212 | 5 | 5 | 0.07% | 0.10% |  |
| B | 7004 | 5212 | 121 | 121 | 1.73% | 2.32% |  |
| C | 7004 | 5212 | 10 | 10 | 0.14% | 0.19% |  |
| D | 7004 | 5212 | 1156 | 1156 | 16.50% | 22.18% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 339205 | 2783.09 | 597 | 585 | 121.7 |
| A | 15 | 222 | 176804 | 1448.33 | 597 | 585 | 121.7 |
| A | 12 | 189 | 45253 | 367.12 | 597 | 585 | 121.7 |
| B | 8 | 3 | 423948 | 3806.63 | 583 | 566 | 111.2 |
| B | 0 | 183 | 143865 | 1288.4 | 583 | 566 | 111.2 |
| B | 4 | 171 | 129678 | 1160.84 | 583 | 566 | 111.2 |
| C | 15 | 214 | 217543 | 1640.31 | 569 | 573 | 132.3 |
| C | 5 | 250 | 80712 | 605.86 | 569 | 573 | 132.3 |
| C | 0 | 10 | 8511 | 60.01 | 569 | 573 | 132.3 |
| D | 12 | 227 | 3332010 | 26823.71 | 512 | 496 | 124.2 |
| D | 7 | 223 | 137903 | 1106.33 | 512 | 496 | 124.2 |
| D | 10 | 118 | 135163 | 1084.27 | 512 | 496 | 124.2 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
