| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A12_018T01_9000005470_39360cztM0_level2.fits | modeM0/AS1A12_018T01_9000005470_39360cztM0_level2_quad_clean.evt |
| Size (bytes) | 373,936,320 | 86,860,800 |
| Size | 356.6 MB | 82.8 MB |
| Events in quadrant A | 2,574,397 | 610,475 |
| Events in quadrant B | 2,286,942 | 631,151 |
| Events in quadrant C | 2,368,153 | 583,842 |
| Events in quadrant D | 6,230,930 | 461,060 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 22 | 0 |
| B | 0 | 22 | 0 |
| C | 0 | 22 | 0 |
| D | 0 | 22 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 100 | 0 |
| B | 0 | 100 | 0 |
| C | 0 | 100 | 0 |
| D | 0 | 100 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 10610 | 3 |
| B | 0 | 10099 | 2 |
| C | 0 | 10039 | 2 |
| D | 0 | 21948 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 4900 | 12 | 0.244898% |
| B | 4900 | 10 | 0.204082% |
| C | 4900 | 8 | 0.163265% |
| D | 4900 | 918 | 18.734694% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7023 | 4901 | 2 | 2 | 0.03% | 0.04% |  |
| B | 7023 | 4901 | 3 | 3 | 0.04% | 0.06% |  |
| C | 7023 | 4901 | 3 | 3 | 0.04% | 0.06% |  |
| D | 7023 | 4901 | 930 | 930 | 13.24% | 18.98% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 376021 | 3329.18 | 561 | 550 | 112.8 |
| A | 13 | 248 | 17778 | 152.76 | 561 | 550 | 112.8 |
| A | 2 | 79 | 8625 | 71.6 | 561 | 550 | 112.8 |
| B | 4 | 170 | 63794 | 601.0 | 556 | 542 | 105.2 |
| B | 5 | 255 | 35132 | 328.66 | 556 | 542 | 105.2 |
| B | 12 | 111 | 13131 | 119.62 | 556 | 542 | 105.2 |
| C | 15 | 214 | 209281 | 1684.47 | 535 | 538 | 123.9 |
| C | 9 | 187 | 44522 | 354.93 | 535 | 538 | 123.9 |
| C | 0 | 10 | 16736 | 130.71 | 535 | 538 | 123.9 |
| D | 12 | 235 | 3244237 | 26891.07 | 500 | 486 | 120.6 |
| D | 2 | 249 | 614071 | 5086.69 | 500 | 486 | 120.6 |
| D | 12 | 227 | 221060 | 1828.58 | 500 | 486 | 120.6 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
