| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A12_018T01_9000005470_39408cztM0_level2.fits | modeM0/AS1A12_018T01_9000005470_39408cztM0_level2_quad_clean.evt |
| Size (bytes) | 499,662,720 | 94,210,560 |
| Size | 476.5 MB | 89.8 MB |
| Events in quadrant A | 3,869,620 | 630,394 |
| Events in quadrant B | 2,725,528 | 661,377 |
| Events in quadrant C | 3,742,827 | 611,369 |
| Events in quadrant D | 7,703,375 | 539,692 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15 | 0 |
| B | 0 | 15 | 0 |
| C | 0 | 15 | 0 |
| D | 0 | 16 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 118 | 0 |
| B | 0 | 118 | 0 |
| C | 0 | 118 | 0 |
| D | 0 | 118 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15114 | 3 |
| B | 0 | 12158 | 2 |
| C | 0 | 14919 | 2 |
| D | 0 | 27012 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5866 | 207 | 3.528810% |
| B | 5866 | 5 | 0.085237% |
| C | 5866 | 112 | 1.909308% |
| D | 5866 | 632 | 10.773952% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7207 | 5867 | 162 | 162 | 2.25% | 2.76% |  |
| B | 7207 | 5867 | 0 | 0 | 0.00% | 0.00% |  |
| C | 7207 | 5867 | 92 | 92 | 1.28% | 1.57% |  |
| D | 7207 | 5867 | 651 | 651 | 9.03% | 11.10% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 248 | 839516 | 6567.9 | 632 | 618 | 127.7 |
| A | 10 | 83 | 458391 | 3584.0 | 632 | 618 | 127.7 |
| A | 6 | 10 | 104605 | 814.14 | 632 | 618 | 127.7 |
| B | 6 | 203 | 148392 | 1201.41 | 633 | 615 | 123.0 |
| B | 5 | 172 | 61008 | 490.99 | 633 | 615 | 123.0 |
| B | 12 | 111 | 15469 | 120.76 | 633 | 615 | 123.0 |
| C | 15 | 208 | 727481 | 5068.18 | 615 | 618 | 143.4 |
| C | 9 | 187 | 251121 | 1746.67 | 615 | 618 | 143.4 |
| C | 15 | 214 | 246460 | 1714.17 | 615 | 618 | 143.4 |
| D | 12 | 235 | 4171049 | 28699.63 | 599 | 581 | 145.3 |
| D | 12 | 227 | 507119 | 3485.81 | 599 | 581 | 145.3 |
| D | 13 | 249 | 431084 | 2962.56 | 599 | 581 | 145.3 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
