| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A12_018T01_9000005488_39624cztM0_level2.fits | modeM0/AS1A12_018T01_9000005488_39624cztM0_level2_quad_clean.evt |
| Size (bytes) | 437,002,560 | 91,290,240 |
| Size | 416.8 MB | 87.1 MB |
| Events in quadrant A | 3,089,266 | 617,970 |
| Events in quadrant B | 2,697,302 | 633,472 |
| Events in quadrant C | 5,273,372 | 581,044 |
| Events in quadrant D | 4,673,944 | 533,538 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 116 | 0 |
| B | 0 | 116 | 0 |
| C | 0 | 116 | 0 |
| D | 0 | 116 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12919 | 3 |
| B | 0 | 12283 | 2 |
| C | 0 | 19679 | 2 |
| D | 0 | 17914 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 34 | 0 |
| B | 0 | 34 | 0 |
| C | 0 | 34 | 0 |
| D | 0 | 35 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5692 | 69 | 1.212228% |
| B | 5692 | 110 | 1.932537% |
| C | 5692 | 531 | 9.328883% |
| D | 5692 | 524 | 9.205903% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7305 | 5693 | 48 | 48 | 0.66% | 0.84% |  |
| B | 7305 | 5693 | 58 | 58 | 0.79% | 1.02% |  |
| C | 7305 | 5693 | 470 | 470 | 6.43% | 8.26% |  |
| D | 7305 | 5693 | 456 | 456 | 6.24% | 8.01% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 451060 | 3686.93 | 598 | 586 | 122.2 |
| A | 15 | 222 | 169492 | 1382.42 | 598 | 586 | 122.2 |
| A | 15 | 174 | 128791 | 1049.3 | 598 | 586 | 122.2 |
| B | 5 | 172 | 277197 | 2400.49 | 595 | 579 | 115.2 |
| B | 5 | 255 | 53635 | 460.42 | 595 | 579 | 115.2 |
| B | 12 | 111 | 14447 | 120.35 | 595 | 579 | 115.2 |
| C | 9 | 187 | 1670043 | 12462.96 | 573 | 576 | 134.0 |
| C | 15 | 208 | 1085685 | 8100.59 | 573 | 576 | 134.0 |
| C | 15 | 214 | 230477 | 1716.26 | 573 | 576 | 134.0 |
| D | 13 | 249 | 1437846 | 10312.32 | 566 | 550 | 139.4 |
| D | 12 | 227 | 650103 | 4660.41 | 566 | 550 | 139.4 |
| D | 1 | 52 | 96558 | 688.84 | 566 | 550 | 139.4 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
