| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A12_056T02_9000005538_40406cztM0_level2.fits | modeM0/AS1A12_056T02_9000005538_40406cztM0_level2_quad_clean.evt |
| Size (bytes) | 341,029,440 | 91,077,120 |
| Size | 325.2 MB | 86.9 MB |
| Events in quadrant A | 3,120,646 | 624,014 |
| Events in quadrant B | 2,839,574 | 636,220 |
| Events in quadrant C | 2,540,948 | 601,763 |
| Events in quadrant D | 3,707,155 | 522,542 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12562 | 3 |
| B | 0 | 12040 | 2 |
| C | 0 | 10849 | 2 |
| D | 0 | 14564 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 30 | 0 |
| B | 0 | 30 | 0 |
| C | 0 | 30 | 0 |
| D | 0 | 31 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 108 | 0 |
| B | 0 | 108 | 0 |
| C | 0 | 108 | 0 |
| D | 0 | 108 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5332 | 23 | 0.431358% |
| B | 5332 | 26 | 0.487622% |
| C | 5332 | 8 | 0.150038% |
| D | 5332 | 342 | 6.414104% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7005 | 5333 | 10 | 10 | 0.14% | 0.19% |  |
| B | 7005 | 5333 | 7 | 7 | 0.10% | 0.13% |  |
| C | 7005 | 5333 | 3 | 3 | 0.04% | 0.06% |  |
| D | 7005 | 5333 | 49 | 49 | 0.70% | 0.92% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 481965 | 4023.53 | 588 | 580 | 119.6 |
| A | 9 | 143 | 296113 | 2470.13 | 588 | 580 | 119.6 |
| A | 13 | 248 | 55238 | 456.84 | 588 | 580 | 119.6 |
| B | 7 | 202 | 320678 | 2827.78 | 586 | 570 | 113.2 |
| B | 4 | 170 | 128990 | 1134.44 | 586 | 570 | 113.2 |
| B | 5 | 255 | 38200 | 332.42 | 586 | 570 | 113.2 |
| C | 15 | 214 | 231902 | 1711.86 | 575 | 580 | 135.1 |
| C | 12 | 249 | 17338 | 124.02 | 575 | 580 | 135.1 |
| C | 14 | 254 | 15130 | 107.68 | 575 | 580 | 135.1 |
| D | 12 | 227 | 968134 | 7139.24 | 549 | 535 | 135.5 |
| D | 2 | 250 | 205355 | 1511.22 | 549 | 535 | 135.5 |
| D | 13 | 171 | 165765 | 1219.11 | 549 | 535 | 135.5 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
