| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1T05_070T01_9000005544_40534cztM0_level2.fits | modeM0/AS1T05_070T01_9000005544_40534cztM0_level2_quad_clean.evt |
| Size (bytes) | 321,868,800 | 84,790,080 |
| Size | 307.0 MB | 80.9 MB |
| Events in quadrant A | 2,937,903 | 600,074 |
| Events in quadrant B | 2,396,640 | 614,786 |
| Events in quadrant C | 2,771,431 | 575,159 |
| Events in quadrant D | 3,416,388 | 425,391 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11734 | 3 |
| B | 0 | 10280 | 2 |
| C | 0 | 11208 | 2 |
| D | 0 | 13441 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 25 | 0 |
| B | 0 | 25 | 0 |
| C | 0 | 25 | 0 |
| D | 0 | 26 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 102 | 0 |
| B | 0 | 102 | 0 |
| C | 0 | 102 | 0 |
| D | 0 | 102 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5019 | 15 | 0.298864% |
| B | 5019 | 12 | 0.239091% |
| C | 5019 | 67 | 1.334927% |
| D | 5019 | 1199 | 23.889221% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7172 | 5020 | 5 | 5 | 0.07% | 0.10% |  |
| B | 7172 | 5020 | 3 | 3 | 0.04% | 0.06% |  |
| C | 7172 | 5020 | 66 | 66 | 0.92% | 1.31% |  |
| D | 7172 | 5020 | 214 | 214 | 2.98% | 4.26% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 491989 | 4158.08 | 577 | 568 | 118.2 |
| A | 12 | 189 | 111911 | 942.11 | 577 | 568 | 118.2 |
| A | 3 | 1 | 74055 | 621.8 | 577 | 568 | 118.2 |
| B | 3 | 112 | 71301 | 641.02 | 569 | 556 | 110.4 |
| B | 0 | 230 | 44678 | 399.79 | 569 | 556 | 110.4 |
| B | 4 | 171 | 18939 | 166.57 | 569 | 556 | 110.4 |
| C | 14 | 254 | 235036 | 1801.63 | 554 | 557 | 130.1 |
| C | 15 | 214 | 223537 | 1713.28 | 554 | 557 | 130.1 |
| C | 10 | 20 | 120006 | 917.79 | 554 | 557 | 130.1 |
| D | 12 | 227 | 729853 | 5906.43 | 495 | 480 | 123.5 |
| D | 2 | 250 | 350450 | 2834.04 | 495 | 480 | 123.5 |
| D | 12 | 191 | 220318 | 1780.24 | 495 | 480 | 123.5 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
