| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A12_029T02_9000005558_40693cztM0_level2.fits | modeM0/AS1A12_029T02_9000005558_40693cztM0_level2_quad_clean.evt |
| Size (bytes) | 320,434,560 | 72,048,960 |
| Size | 305.6 MB | 68.7 MB |
| Events in quadrant A | 2,569,816 | 502,119 |
| Events in quadrant B | 2,243,365 | 520,154 |
| Events in quadrant C | 4,456,009 | 448,210 |
| Events in quadrant D | 2,258,390 | 410,257 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11628 | 1394 |
| B | 0 | 10805 | 1299 |
| C | 0 | 18527 | 2349 |
| D | 0 | 11171 | 1479 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 31 | 0 |
| B | 0 | 31 | 0 |
| C | 0 | 31 | 0 |
| D | 0 | 32 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 97 | 8 |
| B | 0 | 97 | 9 |
| C | 0 | 97 | 9 |
| D | 0 | 99 | 13 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 4299 | 10 | 0.232612% |
| B | 4296 | 36 | 0.837989% |
| C | 4225 | 463 | 10.958580% |
| D | 4279 | 417 | 9.745268% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7246 | 4415 | 4 | 4 | 0.06% | 0.09% |  |
| B | 7246 | 4416 | 16 | 16 | 0.22% | 0.36% |  |
| C | 7246 | 4339 | 457 | 457 | 6.31% | 10.53% |  |
| D | 7246 | 4374 | 34 | 34 | 0.47% | 0.78% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 448914 | 4471.53 | 485 | 476 | 100.3 |
| A | 12 | 189 | 232031 | 2308.91 | 485 | 476 | 100.3 |
| A | 6 | 10 | 6060 | 55.68 | 485 | 476 | 100.3 |
| B | 0 | 229 | 157009 | 1666.48 | 485 | 472 | 93.9 |
| B | 0 | 190 | 88631 | 938.53 | 485 | 472 | 93.9 |
| B | 5 | 255 | 31465 | 329.95 | 485 | 472 | 93.9 |
| C | 9 | 187 | 2508542 | 24176.3 | 446 | 448 | 103.7 |
| C | 15 | 214 | 182880 | 1758.52 | 446 | 448 | 103.7 |
| C | 3 | 233 | 18966 | 178.5 | 446 | 448 | 103.7 |
| D | 12 | 227 | 140251 | 1283.8 | 440 | 429 | 108.9 |
| D | 12 | 191 | 126479 | 1157.35 | 440 | 429 | 108.9 |
| D | 2 | 250 | 91357 | 834.87 | 440 | 429 | 108.9 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
