| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A12_104T02_9000005572_40827cztM0_level2.fits | modeM0/AS1A12_104T02_9000005572_40827cztM0_level2_quad_clean.evt |
| Size (bytes) | 369,074,880 | 104,149,440 |
| Size | 352.0 MB | 99.3 MB |
| Events in quadrant A | 3,509,123 | 696,014 |
| Events in quadrant B | 3,090,617 | 713,293 |
| Events in quadrant C | 3,216,677 | 678,576 |
| Events in quadrant D | 3,347,601 | 618,970 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 31 | 0 |
| B | 0 | 31 | 0 |
| C | 0 | 31 | 0 |
| D | 0 | 31 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13919 | 3 |
| B | 0 | 13558 | 2 |
| C | 0 | 13521 | 2 |
| D | 0 | 14551 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 134 | 0 |
| B | 0 | 134 | 0 |
| C | 0 | 134 | 0 |
| D | 0 | 134 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6395 | 22 | 0.344019% |
| B | 6395 | 36 | 0.562940% |
| C | 6395 | 53 | 0.828772% |
| D | 6395 | 136 | 2.126661% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 9531 | 6397 | 14 | 14 | 0.15% | 0.22% |  |
| B | 9531 | 6397 | 8 | 8 | 0.08% | 0.13% |  |
| C | 9531 | 6397 | 47 | 47 | 0.49% | 0.73% |  |
| D | 9531 | 6397 | 112 | 112 | 1.18% | 1.75% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 565430 | 3889.59 | 709 | 695 | 145.2 |
| A | 15 | 191 | 113860 | 779.42 | 709 | 695 | 145.2 |
| A | 13 | 248 | 64381 | 438.64 | 709 | 695 | 145.2 |
| B | 0 | 190 | 254794 | 1833.51 | 706 | 687 | 138.6 |
| B | 0 | 230 | 24808 | 174.05 | 706 | 687 | 138.6 |
| B | 5 | 255 | 23687 | 165.96 | 706 | 687 | 138.6 |
| C | 15 | 214 | 272997 | 1681.38 | 691 | 695 | 162.0 |
| C | 0 | 10 | 149350 | 917.9 | 691 | 695 | 162.0 |
| C | 14 | 254 | 88981 | 545.14 | 691 | 695 | 162.0 |
| D | 13 | 249 | 351858 | 2090.33 | 686 | 664 | 168.0 |
| D | 2 | 249 | 185380 | 1099.44 | 686 | 664 | 168.0 |
| D | 12 | 233 | 67370 | 397.04 | 686 | 664 | 168.0 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
