| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A12_097T01_9000005574_40863cztM0_level2.fits | modeM0/AS1A12_097T01_9000005574_40863cztM0_level2_quad_clean.evt |
| Size (bytes) | 355,582,080 | 86,538,240 |
| Size | 339.1 MB | 82.5 MB |
| Events in quadrant A | 2,837,986 | 582,377 |
| Events in quadrant B | 3,336,001 | 578,872 |
| Events in quadrant C | 2,681,755 | 572,044 |
| Events in quadrant D | 3,893,771 | 515,137 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 17 | 0 |
| B | 0 | 17 | 0 |
| C | 0 | 17 | 0 |
| D | 0 | 17 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 110 | 0 |
| B | 0 | 110 | 0 |
| C | 0 | 110 | 0 |
| D | 0 | 110 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11778 | 3 |
| B | 0 | 13656 | 2 |
| C | 0 | 11384 | 2 |
| D | 0 | 15237 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5303 | 16 | 0.301716% |
| B | 5303 | 273 | 5.148029% |
| C | 5303 | 39 | 0.735433% |
| D | 5303 | 176 | 3.318876% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7066 | 5304 | 4 | 4 | 0.06% | 0.08% |  |
| B | 7066 | 5304 | 186 | 186 | 2.63% | 3.51% |  |
| C | 7066 | 5304 | 29 | 29 | 0.41% | 0.55% |  |
| D | 7066 | 5304 | 149 | 149 | 2.11% | 2.81% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 504063 | 4248.34 | 576 | 562 | 118.5 |
| A | 13 | 248 | 41776 | 347.75 | 576 | 562 | 118.5 |
| A | 2 | 79 | 27884 | 230.53 | 576 | 562 | 118.5 |
| B | 4 | 171 | 1013677 | 9335.93 | 562 | 545 | 108.5 |
| B | 5 | 255 | 36803 | 334.11 | 562 | 545 | 108.5 |
| B | 0 | 229 | 34452 | 312.45 | 562 | 545 | 108.5 |
| C | 15 | 214 | 222125 | 1672.02 | 566 | 568 | 132.5 |
| C | 14 | 254 | 139544 | 1048.81 | 566 | 568 | 132.5 |
| C | 0 | 10 | 66938 | 500.87 | 566 | 568 | 132.5 |
| D | 12 | 79 | 894565 | 6519.71 | 555 | 539 | 137.1 |
| D | 13 | 249 | 290120 | 2111.78 | 555 | 539 | 137.1 |
| D | 2 | 249 | 204461 | 1487.11 | 555 | 539 | 137.1 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
