| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A12_029T02_9000005590_41045cztM0_level2.fits | modeM0/AS1A12_029T02_9000005590_41045cztM0_level2_quad_clean.evt |
| Size (bytes) | 403,130,880 | 117,103,680 |
| Size | 384.5 MB | 111.7 MB |
| Events in quadrant A | 3,674,354 | 784,048 |
| Events in quadrant B | 3,226,910 | 795,841 |
| Events in quadrant C | 3,453,737 | 771,379 |
| Events in quadrant D | 4,012,840 | 697,815 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 148 | 0 |
| B | 0 | 148 | 0 |
| C | 0 | 148 | 0 |
| D | 0 | 148 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15285 | 3 |
| B | 0 | 14649 | 2 |
| C | 0 | 14767 | 2 |
| D | 0 | 17087 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 28 | 0 |
| B | 0 | 28 | 0 |
| C | 0 | 28 | 0 |
| D | 0 | 28 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7128 | 13 | 0.182379% |
| B | 7128 | 42 | 0.589226% |
| C | 7128 | 26 | 0.364759% |
| D | 7128 | 193 | 2.707632% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 9934 | 7130 | 4 | 4 | 0.04% | 0.06% |  |
| B | 9934 | 7130 | 14 | 14 | 0.14% | 0.20% |  |
| C | 9934 | 7130 | 23 | 23 | 0.23% | 0.32% |  |
| D | 9934 | 7130 | 162 | 162 | 1.63% | 2.27% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 597875 | 3676.81 | 787 | 769 | 162.4 |
| A | 13 | 248 | 15991 | 93.73 | 787 | 769 | 162.4 |
| A | 13 | 254 | 11960 | 68.91 | 787 | 769 | 162.4 |
| B | 8 | 128 | 102899 | 673.05 | 779 | 755 | 151.8 |
| B | 0 | 190 | 33250 | 214.12 | 779 | 755 | 151.8 |
| B | 12 | 111 | 19937 | 126.4 | 779 | 755 | 151.8 |
| C | 15 | 214 | 303363 | 1687.98 | 768 | 771 | 179.3 |
| C | 14 | 254 | 80676 | 445.74 | 768 | 771 | 179.3 |
| C | 0 | 10 | 51514 | 283.07 | 768 | 771 | 179.3 |
| D | 13 | 249 | 370190 | 2017.7 | 756 | 733 | 183.1 |
| D | 13 | 171 | 363249 | 1979.79 | 756 | 733 | 183.1 |
| D | 12 | 0 | 209012 | 1137.47 | 756 | 733 | 183.1 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
