| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A12_052T04_9000005638_41269cztM0_level2.fits | modeM0/AS1A12_052T04_9000005638_41269cztM0_level2_quad_clean.evt |
| Size (bytes) | 328,112,640 | 89,251,200 |
| Size | 312.9 MB | 85.1 MB |
| Events in quadrant A | 3,067,948 | 597,341 |
| Events in quadrant B | 2,363,524 | 620,100 |
| Events in quadrant C | 2,923,121 | 577,284 |
| Events in quadrant D | 3,372,531 | 532,375 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 32 | 0 |
| B | 0 | 32 | 0 |
| C | 0 | 32 | 0 |
| D | 0 | 33 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 108 | 0 |
| B | 0 | 108 | 0 |
| C | 0 | 108 | 0 |
| D | 0 | 108 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12456 | 3 |
| B | 0 | 10850 | 2 |
| C | 0 | 12047 | 2 |
| D | 0 | 13659 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5367 | 100 | 1.863238% |
| B | 5367 | 6 | 0.111794% |
| C | 5367 | 163 | 3.037078% |
| D | 5367 | 218 | 4.061860% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7161 | 5368 | 69 | 69 | 0.96% | 1.29% |  |
| B | 7161 | 5368 | 1 | 1 | 0.01% | 0.02% |  |
| C | 7161 | 5368 | 155 | 155 | 2.16% | 2.89% |  |
| D | 7161 | 5368 | 201 | 201 | 2.81% | 3.74% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 505802 | 4222.02 | 586 | 573 | 119.7 |
| A | 13 | 248 | 272584 | 2273.1 | 586 | 573 | 119.7 |
| A | 2 | 79 | 10167 | 80.17 | 586 | 573 | 119.7 |
| B | 5 | 255 | 32524 | 282.08 | 586 | 569 | 113.3 |
| B | 12 | 111 | 14382 | 121.93 | 586 | 569 | 113.3 |
| B | 11 | 111 | 13335 | 112.69 | 586 | 569 | 113.3 |
| C | 0 | 10 | 452270 | 3324.5 | 575 | 578 | 135.9 |
| C | 15 | 214 | 226363 | 1661.8 | 575 | 578 | 135.9 |
| C | 13 | 61 | 3767 | 23.47 | 575 | 578 | 135.9 |
| D | 1 | 52 | 565653 | 4039.76 | 573 | 558 | 139.9 |
| D | 6 | 239 | 235096 | 1676.67 | 573 | 558 | 139.9 |
| D | 2 | 120 | 148467 | 1057.37 | 573 | 558 | 139.9 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
