| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A12_011T42_9000005640_41283cztM0_level2.fits | modeM0/AS1A12_011T42_9000005640_41283cztM0_level2_quad_clean.evt |
| Size (bytes) | 196,741,440 | 54,607,680 |
| Size | 187.6 MB | 52.1 MB |
| Events in quadrant A | 1,758,449 | 367,157 |
| Events in quadrant B | 1,512,086 | 379,097 |
| Events in quadrant C | 1,897,742 | 344,162 |
| Events in quadrant D | 1,857,452 | 330,708 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 66 | 0 |
| B | 0 | 66 | 0 |
| C | 0 | 66 | 0 |
| D | 0 | 66 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 18 | 0 |
| B | 0 | 18 | 0 |
| C | 0 | 18 | 0 |
| D | 0 | 18 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 7084 | 2 |
| B | 0 | 6687 | 1 |
| C | 0 | 7602 | 1 |
| D | 0 | 7617 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 3279 | 7 | 0.213480% |
| B | 3279 | 3 | 0.091491% |
| C | 3279 | 125 | 3.812138% |
| D | 3279 | 19 | 0.579445% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 5013 | 3280 | 4 | 4 | 0.08% | 0.12% |  |
| B | 5013 | 3280 | 0 | 0 | 0.00% | 0.00% |  |
| C | 5013 | 3280 | 119 | 119 | 2.37% | 3.63% |  |
| D | 5013 | 3280 | 17 | 17 | 0.34% | 0.52% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 282739 | 3561.83 | 376 | 367 | 79.3 |
| A | 2 | 79 | 17321 | 213.86 | 376 | 367 | 79.3 |
| A | 13 | 6 | 5679 | 67.01 | 376 | 367 | 79.3 |
| B | 7 | 202 | 33767 | 446.82 | 373 | 361 | 74.8 |
| B | 12 | 111 | 9573 | 123.22 | 373 | 361 | 74.8 |
| B | 11 | 111 | 8876 | 113.89 | 373 | 361 | 74.8 |
| C | 0 | 10 | 335844 | 3972.73 | 357 | 359 | 84.4 |
| C | 15 | 214 | 136872 | 1616.55 | 357 | 359 | 84.4 |
| C | 15 | 159 | 32899 | 385.33 | 357 | 359 | 84.4 |
| D | 2 | 120 | 173208 | 1931.45 | 363 | 353 | 89.5 |
| D | 2 | 249 | 138110 | 1539.27 | 363 | 353 | 89.5 |
| D | 13 | 249 | 70024 | 778.49 | 363 | 353 | 89.5 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
