| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1T05_110T01_9000005686_41678cztM0_level2.fits | modeM0/AS1T05_110T01_9000005686_41678cztM0_level2_quad_clean.evt |
| Size (bytes) | 288,233,280 | 88,404,480 |
| Size | 274.9 MB | 84.3 MB |
| Events in quadrant A | 2,709,759 | 602,376 |
| Events in quadrant B | 2,254,247 | 609,715 |
| Events in quadrant C | 2,467,258 | 586,059 |
| Events in quadrant D | 2,855,721 | 535,415 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 98 | 0 |
| B | 0 | 98 | 0 |
| C | 0 | 98 | 0 |
| D | 0 | 98 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11079 | 1 |
| B | 0 | 9965 | 1 |
| C | 0 | 10279 | 2 |
| D | 0 | 11829 | 1 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 22 | 0 |
| B | 0 | 22 | 0 |
| C | 0 | 22 | 0 |
| D | 0 | 22 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 4901 | 12 | 0.244848% |
| B | 4902 | 10 | 0.203998% |
| C | 4901 | 47 | 0.958988% |
| D | 4901 | 142 | 2.897368% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7024 | 4902 | 4 | 4 | 0.06% | 0.08% |  |
| B | 7025 | 4903 | 2 | 2 | 0.03% | 0.04% |  |
| C | 7024 | 4902 | 39 | 39 | 0.56% | 0.80% |  |
| D | 7024 | 4902 | 139 | 139 | 1.98% | 2.84% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 483001 | 4233.02 | 557 | 547 | 114.0 |
| A | 13 | 248 | 30268 | 260.77 | 557 | 547 | 114.0 |
| A | 7 | 3 | 13365 | 112.46 | 557 | 547 | 114.0 |
| B | 0 | 190 | 48148 | 451.21 | 553 | 539 | 105.5 |
| B | 5 | 255 | 16848 | 154.57 | 553 | 539 | 105.5 |
| B | 0 | 245 | 16245 | 148.85 | 553 | 539 | 105.5 |
| C | 15 | 214 | 200062 | 1562.69 | 548 | 552 | 127.7 |
| C | 0 | 10 | 128614 | 1003.07 | 548 | 552 | 127.7 |
| C | 13 | 61 | 3597 | 23.85 | 548 | 552 | 127.7 |
| D | 13 | 249 | 349563 | 2633.79 | 546 | 531 | 132.5 |
| D | 2 | 249 | 292212 | 2201.02 | 546 | 531 | 132.5 |
| D | 2 | 234 | 25837 | 190.96 | 546 | 531 | 132.5 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
