| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A12_099T01_9000005716_41903cztM0_level2.fits | modeM0/AS1A12_099T01_9000005716_41903cztM0_level2_quad_clean.evt |
| Size (bytes) | 1,055,911,680 | 244,016,640 |
| Size | 1007.0 MB | 232.7 MB |
| Events in quadrant A | 11,453,859 | 1,592,332 |
| Events in quadrant B | 8,097,420 | 1,677,396 |
| Events in quadrant C | 8,565,591 | 1,566,880 |
| Events in quadrant D | 9,762,539 | 1,476,211 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 42 | 0 |
| B | 0 | 42 | 0 |
| C | 0 | 43 | 0 |
| D | 0 | 43 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 44167 | 4 |
| B | 0 | 35254 | 4 |
| C | 0 | 35457 | 4 |
| D | 0 | 40251 | 4 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 316 | 0 |
| B | 0 | 316 | 0 |
| C | 0 | 316 | 0 |
| D | 0 | 316 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 15589 | 956 | 6.132529% |
| B | 15589 | 376 | 2.411957% |
| C | 15589 | 506 | 3.245879% |
| D | 15589 | 406 | 2.604401% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 19766 | 15592 | 641 | 641 | 3.24% | 4.11% |  |
| B | 19766 | 15592 | 257 | 257 | 1.30% | 1.65% |  |
| C | 19766 | 15592 | 496 | 496 | 2.51% | 3.18% |  |
| D | 19766 | 15592 | 382 | 382 | 1.93% | 2.45% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 14 | 24 | 3752578 | 11222.67 | 1637 | 1602 | 334.2 |
| A | 10 | 83 | 1334428 | 3987.73 | 1637 | 1602 | 334.2 |
| A | 13 | 6 | 19135 | 52.46 | 1637 | 1602 | 334.2 |
| B | 5 | 255 | 1495841 | 4702.44 | 1655 | 1603 | 317.8 |
| B | 12 | 111 | 41450 | 125.4 | 1655 | 1603 | 317.8 |
| B | 11 | 111 | 38811 | 117.1 | 1655 | 1603 | 317.8 |
| C | 0 | 10 | 1639870 | 4375.71 | 1602 | 1607 | 374.4 |
| C | 15 | 214 | 605089 | 1611.87 | 1602 | 1607 | 374.4 |
| C | 0 | 15 | 64722 | 168.58 | 1602 | 1607 | 374.4 |
| D | 12 | 79 | 1334400 | 3375.36 | 1616 | 1572 | 394.9 |
| D | 12 | 6 | 743096 | 1877.9 | 1616 | 1572 | 394.9 |
| D | 13 | 249 | 577385 | 1458.24 | 1616 | 1572 | 394.9 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
