| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1C07_001T10_9000005806_42475cztM0_level2.fits | modeM0/AS1C07_001T10_9000005806_42475cztM0_level2_quad_clean.evt |
| Size (bytes) | 324,656,640 | 84,686,400 |
| Size | 309.6 MB | 80.8 MB |
| Events in quadrant A | 2,766,296 | 585,671 |
| Events in quadrant B | 2,464,904 | 584,022 |
| Events in quadrant C | 2,345,130 | 553,052 |
| Events in quadrant D | 4,061,190 | 499,690 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 24 | 0 |
| B | 0 | 25 | 0 |
| C | 0 | 25 | 0 |
| D | 0 | 25 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 98 | 0 |
| B | 0 | 98 | 0 |
| C | 0 | 98 | 0 |
| D | 0 | 98 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 10985 | 2 |
| B | 0 | 10602 | 2 |
| C | 0 | 10017 | 2 |
| D | 0 | 15396 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 4879 | 11 | 0.225456% |
| B | 4879 | 31 | 0.635376% |
| C | 4879 | 8 | 0.163968% |
| D | 4879 | 341 | 6.989137% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7033 | 4880 | 3 | 3 | 0.04% | 0.06% |  |
| B | 7033 | 4880 | 21 | 21 | 0.30% | 0.43% |  |
| C | 7033 | 4880 | 4 | 4 | 0.06% | 0.08% |  |
| D | 7033 | 4880 | 287 | 287 | 4.08% | 5.88% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 572888 | 5177.89 | 544 | 534 | 110.5 |
| A | 12 | 189 | 43573 | 389.36 | 544 | 534 | 110.5 |
| A | 13 | 6 | 19920 | 175.38 | 544 | 534 | 110.5 |
| B | 0 | 186 | 201617 | 1993.62 | 530 | 517 | 100.9 |
| B | 5 | 172 | 80632 | 794.23 | 530 | 517 | 100.9 |
| B | 15 | 35 | 36023 | 351.99 | 530 | 517 | 100.9 |
| C | 15 | 214 | 209001 | 1728.24 | 521 | 524 | 120.6 |
| C | 15 | 111 | 67189 | 552.64 | 521 | 524 | 120.6 |
| C | 0 | 239 | 19387 | 156.37 | 521 | 524 | 120.6 |
| D | 12 | 233 | 920136 | 7356.16 | 518 | 503 | 125.0 |
| D | 1 | 52 | 326400 | 2606.85 | 518 | 503 | 125.0 |
| D | 2 | 16 | 163347 | 1302.59 | 518 | 503 | 125.0 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
