| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1C07_001T10_9000005856_43155cztM0_level2.fits | modeM0/AS1C07_001T10_9000005856_43155cztM0_level2_quad_clean.evt |
| Size (bytes) | 312,906,240 | 86,713,920 |
| Size | 298.4 MB | 82.7 MB |
| Events in quadrant A | 3,420,483 | 587,265 |
| Events in quadrant B | 2,264,214 | 611,876 |
| Events in quadrant C | 2,625,737 | 560,267 |
| Events in quadrant D | 2,889,444 | 521,950 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15 | 0 |
| B | 0 | 15 | 0 |
| C | 0 | 15 | 0 |
| D | 0 | 15 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 100 | 0 |
| B | 0 | 100 | 0 |
| C | 0 | 100 | 0 |
| D | 0 | 100 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13162 | 3 |
| B | 0 | 10050 | 2 |
| C | 0 | 10780 | 2 |
| D | 0 | 12041 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 4910 | 161 | 3.279022% |
| B | 4911 | 9 | 0.183262% |
| C | 4911 | 9 | 0.183262% |
| D | 4911 | 97 | 1.975158% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7003 | 4911 | 123 | 123 | 1.76% | 2.50% |  |
| B | 7004 | 4912 | 4 | 4 | 0.06% | 0.08% |  |
| C | 7004 | 4912 | 7 | 7 | 0.10% | 0.14% |  |
| D | 7004 | 4912 | 66 | 66 | 0.94% | 1.34% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 553215 | 4953.49 | 548 | 538 | 111.6 |
| A | 15 | 237 | 464183 | 4155.52 | 548 | 538 | 111.6 |
| A | 13 | 248 | 151936 | 1356.94 | 548 | 538 | 111.6 |
| B | 5 | 255 | 40287 | 382.85 | 545 | 531 | 103.8 |
| B | 15 | 85 | 25430 | 239.77 | 545 | 531 | 103.8 |
| B | 0 | 189 | 16410 | 152.91 | 545 | 531 | 103.8 |
| C | 0 | 239 | 270932 | 2216.93 | 524 | 526 | 122.0 |
| C | 15 | 214 | 222653 | 1821.11 | 524 | 526 | 122.0 |
| C | 14 | 254 | 88194 | 718.75 | 524 | 526 | 122.0 |
| D | 1 | 52 | 397462 | 3051.68 | 532 | 517 | 130.1 |
| D | 13 | 249 | 270749 | 2077.52 | 532 | 517 | 130.1 |
| D | 12 | 0 | 86484 | 660.91 | 532 | 517 | 130.1 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
