| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A13_065T02_9000005922_43962cztM0_level2.fits | modeM0/AS1A13_065T02_9000005922_43962cztM0_level2_quad_clean.evt |
| Size (bytes) | 1,779,914,880 | 251,426,880 |
| Size | 1.7 GB | 239.8 MB |
| Events in quadrant A | 27,395,710 | 1,166,689 |
| Events in quadrant B | 9,940,738 | 1,894,211 |
| Events in quadrant C | 9,203,648 | 1,851,934 |
| Events in quadrant D | 17,952,241 | 1,454,658 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 18 | 0 |
| B | 0 | 18 | 0 |
| C | 0 | 18 | 0 |
| D | 0 | 18 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 364 | 0 |
| B | 0 | 364 | 0 |
| C | 0 | 364 | 0 |
| D | 0 | 364 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 94268 | 3 |
| B | 0 | 42205 | 3 |
| C | 0 | 40430 | 3 |
| D | 0 | 65838 | 3 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 18053 | 7320 | 40.547277% |
| B | 18054 | 474 | 2.625457% |
| C | 18054 | 258 | 1.429046% |
| D | 18054 | 2529 | 14.007976% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 19775 | 18056 | 5784 | 5784 | 29.25% | 32.03% |  |
| B | 19776 | 18056 | 202 | 202 | 1.02% | 1.12% |  |
| C | 19776 | 18056 | 205 | 205 | 1.04% | 1.14% |  |
| D | 19776 | 18056 | 2272 | 2272 | 11.49% | 12.58% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 223 | 14483361 | 45788.55 | 1535 | 1498 | 316.3 |
| A | 14 | 238 | 3781356 | 11951.1 | 1535 | 1498 | 316.3 |
| A | 10 | 83 | 2487031 | 7858.72 | 1535 | 1498 | 316.3 |
| B | 0 | 200 | 703562 | 1837.0 | 1952 | 1886 | 382.0 |
| B | 5 | 172 | 379291 | 988.05 | 1952 | 1886 | 382.0 |
| B | 0 | 183 | 324620 | 844.92 | 1952 | 1886 | 382.0 |
| C | 15 | 158 | 866560 | 1893.92 | 1940 | 1949 | 456.5 |
| C | 14 | 254 | 295885 | 643.86 | 1940 | 1949 | 456.5 |
| C | 3 | 233 | 223723 | 485.79 | 1940 | 1949 | 456.5 |
| D | 1 | 52 | 2351157 | 5032.63 | 1844 | 1789 | 466.8 |
| D | 12 | 17 | 1611300 | 3447.77 | 1844 | 1789 | 466.8 |
| D | 5 | 235 | 1310998 | 2804.49 | 1844 | 1789 | 466.8 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
