| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A13_004T09_9000005992_44333cztM0_level2.fits | modeM0/AS1A13_004T09_9000005992_44333cztM0_level2_quad_clean.evt |
| Size (bytes) | 573,560,640 | 122,938,560 |
| Size | 547.0 MB | 117.2 MB |
| Events in quadrant A | 7,263,225 | 761,072 |
| Events in quadrant B | 4,271,739 | 855,223 |
| Events in quadrant C | 3,634,471 | 835,936 |
| Events in quadrant D | 5,462,360 | 732,659 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 158 | 0 |
| B | 0 | 158 | 0 |
| C | 0 | 158 | 0 |
| D | 0 | 158 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 6 | 0 |
| B | 0 | 7 | 0 |
| C | 0 | 7 | 0 |
| D | 0 | 7 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 27446 | 2 |
| B | 0 | 17931 | 2 |
| C | 0 | 16410 | 2 |
| D | 0 | 21627 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7725 | 988 | 12.789644% |
| B | 7725 | 207 | 2.679612% |
| C | 7725 | 43 | 0.556634% |
| D | 7725 | 487 | 6.304207% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7790 | 7726 | 642 | 642 | 8.24% | 8.31% |  |
| B | 7789 | 7725 | 46 | 46 | 0.59% | 0.60% |  |
| C | 7790 | 7726 | 8 | 8 | 0.10% | 0.10% |  |
| D | 7790 | 7726 | 375 | 375 | 4.81% | 4.85% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 223 | 2040783 | 11318.53 | 860 | 841 | 180.2 |
| A | 10 | 83 | 1845058 | 10232.56 | 860 | 841 | 180.2 |
| A | 0 | 243 | 32558 | 175.98 | 860 | 841 | 180.2 |
| B | 5 | 255 | 157545 | 898.53 | 888 | 861 | 174.4 |
| B | 0 | 190 | 100634 | 572.16 | 888 | 861 | 174.4 |
| B | 0 | 199 | 78662 | 446.16 | 888 | 861 | 174.4 |
| C | 14 | 254 | 122874 | 579.4 | 886 | 890 | 210.5 |
| C | 1 | 3 | 22510 | 102.69 | 886 | 890 | 210.5 |
| C | 3 | 233 | 13403 | 59.43 | 886 | 890 | 210.5 |
| D | 13 | 249 | 919572 | 4236.74 | 863 | 836 | 216.8 |
| D | 2 | 153 | 329315 | 1514.78 | 863 | 836 | 216.8 |
| D | 5 | 171 | 276387 | 1270.7 | 863 | 836 | 216.8 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
