| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A13_004T12_9000006020_44758cztM0_level2.fits | modeM0/AS1A13_004T12_9000006020_44758cztM0_level2_quad_clean.evt |
| Size (bytes) | 1,559,773,440 | 282,470,400 |
| Size | 1.5 GB | 269.4 MB |
| Events in quadrant A | 19,948,670 | 1,742,176 |
| Events in quadrant B | 12,261,133 | 1,879,317 |
| Events in quadrant C | 9,114,526 | 1,932,849 |
| Events in quadrant D | 14,954,370 | 1,695,001 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 386 | 0 |
| B | 0 | 386 | 0 |
| C | 0 | 386 | 0 |
| D | 0 | 386 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 74150 | 6 |
| B | 0 | 49402 | 3 |
| C | 0 | 41195 | 3 |
| D | 0 | 57618 | 3 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14 | 0 |
| B | 0 | 14 | 0 |
| C | 0 | 14 | 0 |
| D | 0 | 14 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 18891 | 2429 | 12.857975% |
| B | 18891 | 1383 | 7.320946% |
| C | 18892 | 308 | 1.630320% |
| D | 18892 | 1339 | 7.087656% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 20415 | 18893 | 1511 | 1511 | 7.40% | 8.00% |  |
| B | 20416 | 18894 | 792 | 792 | 3.88% | 4.19% |  |
| C | 20417 | 18895 | 124 | 124 | 0.61% | 0.66% |  |
| D | 20417 | 18895 | 979 | 979 | 4.80% | 5.18% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 223 | 6440228 | 15667.27 | 2006 | 1963 | 410.9 |
| A | 10 | 83 | 5126494 | 12470.35 | 2006 | 1963 | 410.9 |
| A | 13 | 248 | 589091 | 1428.75 | 2006 | 1963 | 410.9 |
| B | 0 | 189 | 1848718 | 4610.97 | 2024 | 1955 | 400.5 |
| B | 12 | 3 | 1530968 | 3817.62 | 2024 | 1955 | 400.5 |
| B | 5 | 255 | 463861 | 1153.28 | 2024 | 1955 | 400.5 |
| C | 14 | 254 | 730023 | 1523.2 | 2044 | 2052 | 477.9 |
| C | 1 | 3 | 312926 | 650.47 | 2044 | 2052 | 477.9 |
| C | 12 | 2 | 53608 | 107.88 | 2044 | 2052 | 477.9 |
| D | 1 | 52 | 2678079 | 5417.94 | 2000 | 1940 | 493.9 |
| D | 2 | 249 | 909659 | 1837.71 | 2000 | 1940 | 493.9 |
| D | 8 | 129 | 904426 | 1827.12 | 2000 | 1940 | 493.9 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
