| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A13_017T02_9000006032_44894cztM0_level2.fits | modeM0/AS1A13_017T02_9000006032_44894cztM0_level2_quad_clean.evt |
| Size (bytes) | 570,147,840 | 117,132,480 |
| Size | 543.7 MB | 111.7 MB |
| Events in quadrant A | 5,543,907 | 803,542 |
| Events in quadrant B | 3,755,800 | 827,678 |
| Events in quadrant C | 3,238,336 | 804,963 |
| Events in quadrant D | 8,068,985 | 661,646 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 132 | 0 |
| B | 0 | 132 | 0 |
| C | 0 | 132 | 0 |
| D | 0 | 132 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 20795 | 1 |
| B | 0 | 15247 | 1 |
| C | 0 | 13544 | 1 |
| D | 0 | 28541 | 1 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12 | 0 |
| B | 0 | 12 | 0 |
| C | 0 | 12 | 0 |
| D | 0 | 12 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6433 | 192 | 2.984611% |
| B | 6433 | 190 | 2.953521% |
| C | 6433 | 73 | 1.134774% |
| D | 6433 | 889 | 13.819369% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7653 | 6435 | 15 | 15 | 0.20% | 0.23% |  |
| B | 7653 | 6435 | 59 | 59 | 0.77% | 0.92% |  |
| C | 7653 | 6435 | 7 | 7 | 0.09% | 0.11% |  |
| D | 7653 | 6435 | 698 | 698 | 9.12% | 10.85% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 2263142 | 13576.11 | 808 | 792 | 166.6 |
| A | 13 | 248 | 103004 | 613.36 | 808 | 792 | 166.6 |
| A | 10 | 248 | 27687 | 161.39 | 808 | 792 | 166.6 |
| B | 7 | 221 | 130283 | 829.37 | 803 | 780 | 156.1 |
| B | 5 | 172 | 100465 | 638.41 | 803 | 780 | 156.1 |
| B | 5 | 255 | 68241 | 432.04 | 803 | 780 | 156.1 |
| C | 12 | 2 | 42361 | 220.48 | 803 | 810 | 188.5 |
| C | 3 | 233 | 29770 | 153.67 | 803 | 810 | 188.5 |
| C | 12 | 250 | 17873 | 90.54 | 803 | 810 | 188.5 |
| D | 13 | 174 | 1766884 | 8966.69 | 773 | 749 | 197.0 |
| D | 13 | 187 | 1138857 | 5778.19 | 773 | 749 | 197.0 |
| D | 1 | 47 | 641324 | 3252.21 | 773 | 749 | 197.0 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
