| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A13_071T03_9000006142_45919cztM0_level2.fits | modeM0/AS1A13_071T03_9000006142_45919cztM0_level2_quad_clean.evt |
| Size (bytes) | 664,931,520 | 93,816,000 |
| Size | 634.1 MB | 89.5 MB |
| Events in quadrant A | 5,658,368 | 662,329 |
| Events in quadrant B | 8,762,450 | 508,508 |
| Events in quadrant C | 2,982,177 | 657,244 |
| Events in quadrant D | 6,723,845 | 572,811 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 21186 | 2 |
| B | 0 | 30424 | 1 |
| C | 0 | 13495 | 1 |
| D | 0 | 24402 | 1 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 10 | 0 |
| B | 0 | 10 | 0 |
| C | 0 | 10 | 0 |
| D | 0 | 10 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 128 | 0 |
| B | 0 | 128 | 0 |
| C | 0 | 128 | 0 |
| D | 0 | 128 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6294 | 195 | 3.098189% |
| B | 6294 | 2007 | 31.887512% |
| C | 6294 | 58 | 0.921513% |
| D | 6295 | 527 | 8.371724% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7284 | 6295 | 56 | 56 | 0.77% | 0.89% |  |
| B | 7284 | 6295 | 1418 | 1418 | 19.47% | 22.53% |  |
| C | 7284 | 6295 | 42 | 42 | 0.58% | 0.67% |  |
| D | 7285 | 6295 | 488 | 488 | 6.70% | 7.75% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 2795458 | 19484.53 | 684 | 669 | 143.4 |
| A | 0 | 247 | 133119 | 923.41 | 684 | 669 | 143.4 |
| A | 13 | 248 | 30672 | 209.17 | 684 | 669 | 143.4 |
| B | 3 | 112 | 5614558 | 45377.5 | 620 | 601 | 123.7 |
| B | 10 | 246 | 591753 | 4778.27 | 620 | 601 | 123.7 |
| B | 4 | 158 | 34784 | 276.3 | 620 | 601 | 123.7 |
| C | 14 | 254 | 175514 | 1091.18 | 673 | 675 | 160.2 |
| C | 12 | 249 | 126117 | 782.89 | 673 | 675 | 160.2 |
| C | 5 | 250 | 41480 | 254.67 | 673 | 675 | 160.2 |
| D | 11 | 241 | 1912885 | 11474.94 | 655 | 633 | 166.6 |
| D | 1 | 52 | 1498884 | 8990.63 | 655 | 633 | 166.6 |
| D | 13 | 249 | 317017 | 1898.54 | 655 | 633 | 166.6 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
