| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A13_033T03_9000006144_45941cztM0_level2.fits | modeM0/AS1A13_033T03_9000006144_45941cztM0_level2_quad_clean.evt |
| Size (bytes) | 545,713,920 | 105,802,560 |
| Size | 520.4 MB | 100.9 MB |
| Events in quadrant A | 5,695,636 | 706,299 |
| Events in quadrant B | 6,149,504 | 668,663 |
| Events in quadrant C | 3,123,971 | 720,741 |
| Events in quadrant D | 4,702,969 | 632,968 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 5 | 0 |
| B | 0 | 5 | 0 |
| C | 0 | 5 | 0 |
| D | 0 | 5 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 21247 | 1 |
| B | 0 | 22865 | 3 |
| C | 0 | 14284 | 1 |
| D | 0 | 18538 | 1 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 138 | 0 |
| B | 0 | 138 | 0 |
| C | 0 | 138 | 0 |
| D | 0 | 138 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6813 | 218 | 3.199765% |
| B | 6812 | 947 | 13.901938% |
| C | 6812 | 67 | 0.983558% |
| D | 6813 | 404 | 5.929840% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7268 | 6813 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7267 | 6812 | 598 | 598 | 8.23% | 8.78% |  |
| C | 7267 | 6813 | 15 | 15 | 0.21% | 0.22% |  |
| D | 7268 | 6814 | 299 | 299 | 4.11% | 4.39% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 2692730 | 16663.99 | 766 | 748 | 161.5 |
| A | 0 | 247 | 25879 | 155.57 | 766 | 748 | 161.5 |
| A | 2 | 79 | 12294 | 71.47 | 766 | 748 | 161.5 |
| B | 3 | 112 | 3148933 | 21456.02 | 730 | 707 | 146.7 |
| B | 4 | 158 | 48147 | 323.32 | 730 | 707 | 146.7 |
| B | 4 | 171 | 30823 | 205.25 | 730 | 707 | 146.7 |
| C | 2 | 14 | 72743 | 405.11 | 755 | 759 | 177.7 |
| C | 14 | 254 | 50282 | 278.71 | 755 | 759 | 177.7 |
| C | 12 | 2 | 20028 | 108.44 | 755 | 759 | 177.7 |
| D | 12 | 233 | 481433 | 2540.53 | 745 | 721 | 189.2 |
| D | 1 | 47 | 469132 | 2475.52 | 745 | 721 | 189.2 |
| D | 6 | 143 | 361927 | 1908.95 | 745 | 721 | 189.2 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
