| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A13_071T06_9000006146_45958cztM0_level2.fits | modeM0/AS1A13_071T06_9000006146_45958cztM0_level2_quad_clean.evt |
| Size (bytes) | 812,908,800 | 127,488,960 |
| Size | 775.3 MB | 121.6 MB |
| Events in quadrant A | 7,124,564 | 872,857 |
| Events in quadrant B | 8,964,661 | 829,156 |
| Events in quadrant C | 3,703,420 | 867,844 |
| Events in quadrant D | 9,661,812 | 716,262 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 25993 | 0 |
| B | 0 | 32432 | 0 |
| C | 0 | 17117 | 0 |
| D | 0 | 34395 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 166 | 0 |
| B | 0 | 166 | 0 |
| C | 0 | 166 | 0 |
| D | 0 | 166 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 8251 | 154 | 1.866440% |
| B | 8251 | 1131 | 13.707429% |
| C | 8252 | 8 | 0.096946% |
| D | 8252 | 1042 | 12.627242% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 8251 | 8251 | 2 | 2 | 0.02% | 0.02% |  |
| B | 8251 | 8251 | 885 | 885 | 10.73% | 10.73% |  |
| C | 8252 | 8252 | 7 | 7 | 0.08% | 0.08% |  |
| D | 8252 | 8252 | 889 | 889 | 10.77% | 10.77% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 3407747 | 17276.35 | 935 | 913 | 197.2 |
| A | 14 | 235 | 43109 | 213.98 | 935 | 913 | 197.2 |
| A | 0 | 247 | 25863 | 126.52 | 935 | 913 | 197.2 |
| B | 3 | 112 | 4768377 | 26892.55 | 896 | 868 | 177.3 |
| B | 4 | 21 | 493742 | 2780.2 | 896 | 868 | 177.3 |
| B | 0 | 186 | 46152 | 255.44 | 896 | 868 | 177.3 |
| C | 14 | 254 | 50848 | 231.96 | 917 | 920 | 215.2 |
| C | 2 | 14 | 33376 | 150.79 | 917 | 920 | 215.2 |
| C | 3 | 9 | 23596 | 105.35 | 917 | 920 | 215.2 |
| D | 11 | 241 | 5047777 | 22685.25 | 880 | 854 | 222.5 |
| D | 1 | 52 | 731447 | 3283.92 | 880 | 854 | 222.5 |
| D | 13 | 249 | 136658 | 610.42 | 880 | 854 | 222.5 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
