| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A13_077T01_9000006168_46091cztM0_level2.fits | modeM0/AS1A13_077T01_9000006168_46091cztM0_level2_quad_clean.evt |
| Size (bytes) | 1,022,469,120 | 231,370,560 |
| Size | 975.1 MB | 220.7 MB |
| Events in quadrant A | 12,752,271 | 1,506,391 |
| Events in quadrant B | 7,647,260 | 1,570,306 |
| Events in quadrant C | 6,981,675 | 1,541,373 |
| Events in quadrant D | 9,321,754 | 1,365,244 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 46364 | 2 |
| B | 0 | 32675 | 2 |
| C | 0 | 31377 | 2 |
| D | 0 | 37813 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 302 | 0 |
| B | 0 | 302 | 0 |
| C | 0 | 302 | 0 |
| D | 0 | 302 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 7 | 0 |
| B | 0 | 7 | 0 |
| C | 0 | 7 | 0 |
| D | 0 | 7 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 14802 | 623 | 4.208891% |
| B | 14803 | 532 | 3.593866% |
| C | 14803 | 249 | 1.682091% |
| D | 14803 | 752 | 5.080051% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 15572 | 14806 | 4 | 4 | 0.03% | 0.03% |  |
| B | 15573 | 14806 | 40 | 40 | 0.26% | 0.27% |  |
| C | 15573 | 14806 | 37 | 37 | 0.24% | 0.25% |  |
| D | 15573 | 14806 | 434 | 434 | 2.79% | 2.93% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 5914779 | 16691.68 | 1699 | 1661 | 354.3 |
| A | 9 | 191 | 120934 | 336.69 | 1699 | 1661 | 354.3 |
| A | 14 | 235 | 89584 | 248.19 | 1699 | 1661 | 354.3 |
| B | 0 | 190 | 515465 | 1527.74 | 1696 | 1639 | 336.3 |
| B | 5 | 172 | 178409 | 525.58 | 1696 | 1639 | 336.3 |
| B | 3 | 112 | 108283 | 317.08 | 1696 | 1639 | 336.3 |
| C | 14 | 254 | 369269 | 924.72 | 1686 | 1694 | 397.5 |
| C | 3 | 233 | 27663 | 65.33 | 1686 | 1694 | 397.5 |
| C | 12 | 2 | 15514 | 34.77 | 1686 | 1694 | 397.5 |
| D | 5 | 235 | 869930 | 2063.23 | 1664 | 1612 | 420.9 |
| D | 1 | 52 | 626429 | 1484.64 | 1664 | 1612 | 420.9 |
| D | 13 | 249 | 589795 | 1397.59 | 1664 | 1612 | 420.9 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
