| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A13_093T12_9000006184_46216cztM0_level2.fits | modeM0/AS1A13_093T12_9000006184_46216cztM0_level2_quad_clean.evt |
| Size (bytes) | 505,929,600 | 114,863,040 |
| Size | 482.5 MB | 109.5 MB |
| Events in quadrant A | 6,583,485 | 730,073 |
| Events in quadrant B | 3,859,454 | 793,560 |
| Events in quadrant C | 3,538,746 | 775,342 |
| Events in quadrant D | 4,207,019 | 695,410 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 24346 | 5 |
| B | 0 | 16208 | 5 |
| C | 0 | 15464 | 4 |
| D | 0 | 17498 | 14 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 20 | 0 |
| B | 0 | 20 | 0 |
| C | 0 | 20 | 0 |
| D | 0 | 20 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 142 | 0 |
| B | 0 | 142 | 0 |
| C | 0 | 142 | 0 |
| D | 0 | 142 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6947 | 481 | 6.923852% |
| B | 6947 | 142 | 2.044048% |
| C | 6947 | 132 | 1.900101% |
| D | 6945 | 217 | 3.124550% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 8903 | 6949 | 117 | 117 | 1.31% | 1.68% |  |
| B | 8903 | 6950 | 12 | 12 | 0.13% | 0.17% |  |
| C | 8903 | 6950 | 73 | 73 | 0.82% | 1.05% |  |
| D | 8903 | 6950 | 115 | 115 | 1.29% | 1.65% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 3153396 | 19702.39 | 770 | 753 | 160.0 |
| A | 9 | 191 | 300098 | 1870.75 | 770 | 753 | 160.0 |
| A | 13 | 248 | 71617 | 442.86 | 770 | 753 | 160.0 |
| B | 3 | 112 | 608985 | 4010.1 | 786 | 761 | 151.7 |
| B | 5 | 255 | 69713 | 454.61 | 786 | 761 | 151.7 |
| B | 12 | 111 | 19725 | 125.03 | 786 | 761 | 151.7 |
| C | 12 | 2 | 225127 | 1222.63 | 784 | 785 | 183.5 |
| C | 14 | 254 | 164704 | 893.33 | 784 | 785 | 183.5 |
| C | 5 | 49 | 63978 | 344.39 | 784 | 785 | 183.5 |
| D | 1 | 52 | 935042 | 4854.08 | 772 | 748 | 192.5 |
| D | 12 | 128 | 101693 | 524.45 | 772 | 748 | 192.5 |
| D | 2 | 249 | 68523 | 352.12 | 772 | 748 | 192.5 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
