| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A13_072T02_9000006194_46290cztM0_level2.fits | modeM0/AS1A13_072T02_9000006194_46290cztM0_level2_quad_clean.evt |
| Size (bytes) | 582,399,360 | 129,654,720 |
| Size | 555.4 MB | 123.6 MB |
| Events in quadrant A | 6,675,823 | 863,498 |
| Events in quadrant B | 5,865,780 | 877,538 |
| Events in quadrant C | 3,830,501 | 865,468 |
| Events in quadrant D | 4,564,323 | 761,470 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 1 | 0 |
| B | 0 | 2 | 0 |
| C | 0 | 2 | 0 |
| D | 0 | 2 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 25148 | 1 |
| B | 0 | 23129 | 1 |
| C | 0 | 17157 | 1 |
| D | 0 | 19613 | 1 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 160 | 0 |
| B | 0 | 160 | 0 |
| C | 0 | 160 | 0 |
| D | 0 | 160 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 8030 | 209 | 2.602740% |
| B | 8030 | 267 | 3.325031% |
| C | 8030 | 60 | 0.747198% |
| D | 8029 | 344 | 4.284469% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 8030 | 8030 | 1 | 1 | 0.01% | 0.01% |  |
| B | 8030 | 8030 | 23 | 23 | 0.29% | 0.29% |  |
| C | 8030 | 8030 | 5 | 5 | 0.06% | 0.06% |  |
| D | 8029 | 8029 | 254 | 254 | 3.16% | 3.16% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 2995869 | 15127.32 | 943 | 921 | 198.0 |
| A | 9 | 191 | 14865 | 70.43 | 943 | 921 | 198.0 |
| A | 13 | 254 | 12233 | 57.14 | 943 | 921 | 198.0 |
| B | 3 | 112 | 1823082 | 9702.01 | 929 | 895 | 187.8 |
| B | 0 | 190 | 148694 | 786.94 | 929 | 895 | 187.8 |
| B | 4 | 171 | 123634 | 653.51 | 929 | 895 | 187.8 |
| C | 1 | 3 | 116946 | 523.8 | 935 | 939 | 221.5 |
| C | 12 | 2 | 37257 | 163.99 | 935 | 939 | 221.5 |
| C | 14 | 67 | 12793 | 53.52 | 935 | 939 | 221.5 |
| D | 13 | 249 | 967671 | 4200.03 | 905 | 877 | 230.2 |
| D | 13 | 171 | 87048 | 374.35 | 905 | 877 | 230.2 |
| D | 5 | 171 | 40356 | 171.51 | 905 | 877 | 230.2 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
