| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A13_070T05_9000006198_46347cztM0_level2.fits | modeM0/AS1A13_070T05_9000006198_46347cztM0_level2_quad_clean.evt |
| Size (bytes) | 594,112,320 | 102,663,360 |
| Size | 566.6 MB | 97.9 MB |
| Events in quadrant A | 9,090,106 | 535,234 |
| Events in quadrant B | 3,605,800 | 750,883 |
| Events in quadrant C | 3,299,195 | 728,746 |
| Events in quadrant D | 5,463,600 | 614,311 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 4 | 0 |
| B | 0 | 4 | 0 |
| C | 0 | 4 | 0 |
| D | 0 | 4 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 142 | 0 |
| B | 0 | 142 | 0 |
| C | 0 | 142 | 0 |
| D | 0 | 142 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 31472 | 1 |
| B | 0 | 15543 | 1 |
| C | 0 | 14933 | 1 |
| D | 0 | 21028 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6869 | 2036 | 29.640413% |
| B | 6870 | 208 | 3.027656% |
| C | 6870 | 76 | 1.106259% |
| D | 6870 | 683 | 9.941776% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7338 | 6870 | 1140 | 1140 | 15.54% | 16.59% |  |
| B | 7340 | 6872 | 73 | 73 | 0.99% | 1.06% |  |
| C | 7340 | 6872 | 37 | 37 | 0.50% | 0.54% |  |
| D | 7340 | 6872 | 444 | 444 | 6.05% | 6.46% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 223 | 3724845 | 27416.7 | 646 | 632 | 135.8 |
| A | 10 | 83 | 2720781 | 20025.04 | 646 | 632 | 135.8 |
| A | 13 | 248 | 100852 | 737.79 | 646 | 632 | 135.8 |
| B | 5 | 172 | 388917 | 2551.97 | 765 | 740 | 152.1 |
| B | 3 | 112 | 47302 | 306.11 | 765 | 740 | 152.1 |
| B | 15 | 201 | 47064 | 304.55 | 765 | 740 | 152.1 |
| C | 12 | 2 | 247644 | 1374.61 | 762 | 765 | 179.6 |
| C | 12 | 249 | 35790 | 195.02 | 762 | 765 | 179.6 |
| C | 1 | 3 | 21449 | 115.17 | 762 | 765 | 179.6 |
| D | 12 | 1 | 1075454 | 5866.61 | 733 | 710 | 183.2 |
| D | 5 | 235 | 492375 | 2683.81 | 733 | 710 | 183.2 |
| D | 1 | 52 | 451594 | 2461.2 | 733 | 710 | 183.2 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
