| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A13_068T02_9000006200_46373cztM0_level2.fits | modeM0/AS1A13_068T02_9000006200_46373cztM0_level2_quad_clean.evt |
| Size (bytes) | 504,106,560 | 113,990,400 |
| Size | 480.8 MB | 108.7 MB |
| Events in quadrant A | 6,207,982 | 772,039 |
| Events in quadrant B | 3,971,589 | 793,982 |
| Events in quadrant C | 3,684,164 | 760,912 |
| Events in quadrant D | 4,294,556 | 673,385 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 132 | 0 |
| B | 0 | 132 | 0 |
| C | 0 | 132 | 0 |
| D | 0 | 132 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 22324 | 3 |
| B | 0 | 15938 | 3 |
| C | 0 | 15230 | 4 |
| D | 0 | 16941 | 3 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 19 | 0 |
| B | 0 | 20 | 0 |
| C | 0 | 20 | 0 |
| D | 0 | 20 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6472 | 333 | 5.145241% |
| B | 6472 | 332 | 5.129790% |
| C | 6471 | 159 | 2.457116% |
| D | 6471 | 390 | 6.026889% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7652 | 6474 | 28 | 28 | 0.37% | 0.43% |  |
| B | 7652 | 6474 | 158 | 158 | 2.06% | 2.44% |  |
| C | 7651 | 6473 | 45 | 45 | 0.59% | 0.70% |  |
| D | 7651 | 6473 | 204 | 204 | 2.67% | 3.15% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 3023714 | 18206.71 | 797 | 781 | 166.0 |
| A | 2 | 79 | 61852 | 367.82 | 797 | 781 | 166.0 |
| A | 13 | 248 | 19914 | 115.24 | 797 | 781 | 166.0 |
| B | 15 | 201 | 404381 | 2611.92 | 786 | 760 | 154.5 |
| B | 4 | 171 | 256706 | 1656.28 | 786 | 760 | 154.5 |
| B | 5 | 255 | 121482 | 781.22 | 786 | 760 | 154.5 |
| C | 14 | 254 | 560239 | 3106.48 | 775 | 781 | 180.1 |
| C | 12 | 249 | 28965 | 156.5 | 775 | 781 | 180.1 |
| C | 1 | 3 | 23330 | 125.21 | 775 | 781 | 180.1 |
| D | 5 | 235 | 547128 | 2852.2 | 771 | 751 | 191.6 |
| D | 1 | 52 | 328681 | 1711.86 | 771 | 751 | 191.6 |
| D | 13 | 249 | 252134 | 1312.27 | 771 | 751 | 191.6 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
