| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A13_070T06_9000006202_46383cztM0_level2.fits | modeM0/AS1A13_070T06_9000006202_46383cztM0_level2_quad_clean.evt |
| Size (bytes) | 520,715,520 | 106,551,360 |
| Size | 496.6 MB | 101.6 MB |
| Events in quadrant A | 6,102,296 | 694,132 |
| Events in quadrant B | 5,163,215 | 691,723 |
| Events in quadrant C | 2,889,290 | 726,861 |
| Events in quadrant D | 4,598,646 | 644,481 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 22411 | 1 |
| B | 0 | 20064 | 1 |
| C | 0 | 13705 | 1 |
| D | 0 | 18454 | 1 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11 | 0 |
| B | 0 | 11 | 0 |
| C | 0 | 12 | 0 |
| D | 0 | 12 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 136 | 0 |
| B | 0 | 136 | 0 |
| C | 0 | 136 | 0 |
| D | 0 | 136 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6725 | 190 | 2.825279% |
| B | 6725 | 667 | 9.918216% |
| C | 6724 | 19 | 0.282570% |
| D | 6724 | 244 | 3.628792% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7725 | 6726 | 39 | 39 | 0.50% | 0.58% |  |
| B | 7725 | 6726 | 396 | 396 | 5.13% | 5.89% |  |
| C | 7724 | 6725 | 10 | 10 | 0.13% | 0.15% |  |
| D | 7724 | 6725 | 181 | 181 | 2.34% | 2.69% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 3139647 | 21021.11 | 721 | 705 | 149.3 |
| A | 0 | 247 | 143958 | 959.35 | 721 | 705 | 149.3 |
| A | 0 | 226 | 13971 | 88.84 | 721 | 705 | 149.3 |
| B | 5 | 255 | 1484357 | 10726.87 | 704 | 683 | 138.3 |
| B | 4 | 171 | 626009 | 4521.07 | 704 | 683 | 138.3 |
| B | 5 | 32 | 139746 | 1005.42 | 704 | 683 | 138.3 |
| C | 1 | 3 | 60660 | 353.08 | 721 | 724 | 169.8 |
| C | 14 | 254 | 17732 | 100.19 | 721 | 724 | 169.8 |
| C | 13 | 61 | 4821 | 24.13 | 721 | 724 | 169.8 |
| D | 1 | 52 | 1158854 | 6560.01 | 703 | 682 | 176.6 |
| D | 13 | 249 | 583972 | 3303.82 | 703 | 682 | 176.6 |
| D | 8 | 176 | 82317 | 462.39 | 703 | 682 | 176.6 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
