| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A13_070T04_9000006204_46406cztM0_level2.fits | modeM0/AS1A13_070T04_9000006204_46406cztM0_level2_quad_clean.evt |
| Size (bytes) | 483,975,360 | 115,873,920 |
| Size | 461.6 MB | 110.5 MB |
| Events in quadrant A | 6,467,846 | 776,967 |
| Events in quadrant B | 3,696,224 | 797,417 |
| Events in quadrant C | 3,544,762 | 743,831 |
| Events in quadrant D | 3,648,683 | 689,818 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 144 | 0 |
| B | 0 | 144 | 0 |
| C | 0 | 144 | 0 |
| D | 0 | 144 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 24254 | 0 |
| B | 0 | 16029 | 2 |
| C | 0 | 15885 | 0 |
| D | 0 | 16150 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7184 | 87 | 1.211024% |
| B | 7183 | 81 | 1.127663% |
| C | 7185 | 138 | 1.920668% |
| D | 7185 | 106 | 1.475296% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7184 | 7184 | 9 | 9 | 0.13% | 0.13% |  |
| B | 7184 | 7184 | 43 | 43 | 0.60% | 0.60% |  |
| C | 7185 | 7185 | 92 | 92 | 1.28% | 1.28% |  |
| D | 7185 | 7185 | 69 | 69 | 0.96% | 0.96% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 3291207 | 19717.7 | 797 | 779 | 166.9 |
| A | 13 | 248 | 69251 | 410.31 | 797 | 779 | 166.9 |
| A | 13 | 254 | 12851 | 72.34 | 797 | 779 | 166.9 |
| B | 5 | 172 | 264994 | 1681.11 | 796 | 768 | 157.2 |
| B | 2 | 2 | 78918 | 497.22 | 796 | 768 | 157.2 |
| B | 0 | 155 | 52271 | 327.68 | 796 | 768 | 157.2 |
| C | 14 | 254 | 408795 | 2201.78 | 780 | 781 | 185.3 |
| C | 12 | 2 | 36450 | 192.48 | 780 | 781 | 185.3 |
| C | 3 | 233 | 27371 | 143.49 | 780 | 781 | 185.3 |
| D | 5 | 235 | 171079 | 868.16 | 784 | 760 | 196.2 |
| D | 2 | 37 | 94132 | 475.94 | 784 | 760 | 196.2 |
| D | 12 | 233 | 84204 | 425.34 | 784 | 760 | 196.2 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
