| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A13_033T03_9000006206_46422cztM0_level2.fits | modeM0/AS1A13_033T03_9000006206_46422cztM0_level2_quad_clean.evt |
| Size (bytes) | 651,479,040 | 131,794,560 |
| Size | 621.3 MB | 125.7 MB |
| Events in quadrant A | 7,118,120 | 887,422 |
| Events in quadrant B | 3,942,368 | 914,003 |
| Events in quadrant C | 3,771,390 | 877,498 |
| Events in quadrant D | 8,648,683 | 741,571 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 164 | 0 |
| B | 0 | 164 | 0 |
| C | 0 | 164 | 0 |
| D | 0 | 164 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 26255 | 0 |
| B | 0 | 17458 | 0 |
| C | 0 | 16991 | 0 |
| D | 0 | 31372 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 8205 | 101 | 1.230957% |
| B | 8204 | 59 | 0.719161% |
| C | 8205 | 19 | 0.231566% |
| D | 8205 | 897 | 10.932358% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 8205 | 8205 | 0 | 0 | 0.00% | 0.00% |  |
| B | 8204 | 8204 | 11 | 11 | 0.13% | 0.13% |  |
| C | 8205 | 8205 | 1 | 1 | 0.01% | 0.01% |  |
| D | 8205 | 8205 | 637 | 637 | 7.76% | 7.76% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 3260265 | 16428.95 | 946 | 924 | 198.4 |
| A | 0 | 247 | 182463 | 915.06 | 946 | 924 | 198.4 |
| A | 0 | 226 | 17477 | 83.44 | 946 | 924 | 198.4 |
| B | 0 | 190 | 91791 | 483.38 | 944 | 912 | 188.0 |
| B | 0 | 245 | 38820 | 201.63 | 944 | 912 | 188.0 |
| B | 0 | 189 | 33608 | 173.91 | 944 | 912 | 188.0 |
| C | 9 | 54 | 71324 | 318.2 | 937 | 942 | 221.2 |
| C | 3 | 233 | 32680 | 143.49 | 937 | 942 | 221.2 |
| C | 1 | 3 | 8799 | 35.52 | 937 | 942 | 221.2 |
| D | 8 | 129 | 3295792 | 14554.46 | 902 | 874 | 226.4 |
| D | 13 | 249 | 1319446 | 5824.46 | 902 | 874 | 226.4 |
| D | 13 | 138 | 182213 | 801.02 | 902 | 874 | 226.4 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
