| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A13_037T01_9000006212_46458cztM0_level2.fits | modeM0/AS1A13_037T01_9000006212_46458cztM0_level2_quad_clean.evt |
| Size (bytes) | 492,059,520 | 108,745,920 |
| Size | 469.3 MB | 103.7 MB |
| Events in quadrant A | 6,271,515 | 727,660 |
| Events in quadrant B | 3,442,156 | 764,510 |
| Events in quadrant C | 3,277,200 | 716,888 |
| Events in quadrant D | 4,716,321 | 627,843 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14 | 0 |
| B | 0 | 14 | 0 |
| C | 0 | 15 | 0 |
| D | 0 | 15 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 132 | 0 |
| B | 0 | 132 | 0 |
| C | 0 | 132 | 0 |
| D | 0 | 132 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 23060 | 2 |
| B | 0 | 14622 | 2 |
| C | 0 | 14366 | 2 |
| D | 0 | 18728 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6538 | 230 | 3.517895% |
| B | 6538 | 73 | 1.116549% |
| C | 6538 | 133 | 2.034261% |
| D | 6538 | 454 | 6.944020% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7683 | 6539 | 47 | 47 | 0.61% | 0.72% |  |
| B | 7683 | 6539 | 17 | 17 | 0.22% | 0.26% |  |
| C | 7683 | 6538 | 100 | 100 | 1.30% | 1.53% |  |
| D | 7683 | 6539 | 375 | 375 | 4.88% | 5.73% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 3334498 | 22034.37 | 734 | 719 | 151.3 |
| A | 2 | 79 | 38365 | 248.82 | 734 | 719 | 151.3 |
| A | 13 | 254 | 12495 | 77.83 | 734 | 719 | 151.3 |
| B | 0 | 190 | 114352 | 777.01 | 744 | 723 | 146.2 |
| B | 10 | 128 | 69338 | 469.2 | 744 | 723 | 146.2 |
| B | 5 | 172 | 66344 | 448.72 | 744 | 723 | 146.2 |
| C | 9 | 54 | 321317 | 1904.69 | 722 | 725 | 168.3 |
| C | 3 | 233 | 69922 | 411.11 | 722 | 725 | 168.3 |
| C | 12 | 249 | 35580 | 207.08 | 722 | 725 | 168.3 |
| D | 1 | 52 | 862810 | 4921.43 | 694 | 670 | 175.2 |
| D | 2 | 249 | 783183 | 4466.89 | 694 | 670 | 175.2 |
| D | 12 | 233 | 143314 | 814.27 | 694 | 670 | 175.2 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
