| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A13_037T05_9000006216_46484cztM0_level2.fits | modeM0/AS1A13_037T05_9000006216_46484cztM0_level2_quad_clean.evt |
| Size (bytes) | 2,144,770,560 | 373,152,960 |
| Size | 2.0 GB | 355.9 MB |
| Events in quadrant A | 21,964,164 | 2,710,772 |
| Events in quadrant B | 30,092,548 | 1,864,278 |
| Events in quadrant C | 10,627,433 | 2,644,565 |
| Events in quadrant D | 14,861,292 | 2,429,819 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 80903 | 4 |
| B | 0 | 105814 | 4 |
| C | 0 | 49170 | 5 |
| D | 0 | 61131 | 4 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 490 | 0 |
| B | 0 | 490 | 0 |
| C | 0 | 490 | 0 |
| D | 0 | 490 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 20 | 0 |
| B | 0 | 20 | 0 |
| C | 0 | 20 | 0 |
| D | 0 | 20 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 23941 | 742 | 3.099286% |
| B | 23942 | 7253 | 30.294044% |
| C | 23941 | 81 | 0.338332% |
| D | 23941 | 583 | 2.435153% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 26051 | 23943 | 126 | 126 | 0.48% | 0.53% |  |
| B | 26052 | 23944 | 5990 | 5990 | 22.99% | 25.02% |  |
| C | 26051 | 23945 | 6 | 6 | 0.02% | 0.03% |  |
| D | 26051 | 23945 | 410 | 410 | 1.57% | 1.71% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 10578075 | 18675.89 | 2729 | 2678 | 566.3 |
| A | 0 | 247 | 569615 | 1001.2 | 2729 | 2678 | 566.3 |
| A | 13 | 248 | 116898 | 201.71 | 2729 | 2678 | 566.3 |
| B | 10 | 128 | 18096282 | 38103.48 | 2411 | 2340 | 474.9 |
| B | 5 | 32 | 1830799 | 3850.5 | 2411 | 2340 | 474.9 |
| B | 5 | 255 | 250009 | 521.56 | 2411 | 2340 | 474.9 |
| C | 3 | 233 | 68728 | 103.72 | 2689 | 2704 | 636.5 |
| C | 12 | 249 | 34597 | 50.1 | 2689 | 2704 | 636.5 |
| C | 9 | 54 | 20338 | 27.7 | 2689 | 2704 | 636.5 |
| D | 1 | 52 | 2829448 | 4226.15 | 2668 | 2594 | 668.9 |
| D | 2 | 249 | 541605 | 805.82 | 2668 | 2594 | 668.9 |
| D | 13 | 249 | 420776 | 625.18 | 2668 | 2594 | 668.9 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
